Hikvision DS-2SF8C442MXS-DLW(24F0)(P3) 4MP TandemVu 42x Zoom PTZ
Model/varenr.:
DS-2SF8C442MXS-DLW
25.199,00
m/Moms
(
20.159,20
u/Moms
)
Lager:
På lager og klar til afsendelse På lager - afsendes indenfor 1 til 2 hverdage
På lager og klar til afsendelse På lager - afsendes indenfor 1 til 2 hverdage
Har du spørgsmål til produktet?
Bare giv os et kald på 70701009
Bare giv os et kald på 70701009
- Camera
- Image Sensor[Panoramic channel] 1/1.8" Progressive Scan CMOS, [PTZ channel] 1/1.8" Progressive Scan CMOS
- Min. Illumination[Panoramic channel] Color: 0.0005 Lux @ (F1.0, AGC ON), B/W: 0.0001 Lux @ (F1.0, AGC ON), 0 Lux with Light, [PTZ channel] Color: 0.0005 Lux @ (F1.2, AGC ON), B/W: 0.0001 Lux @ (F1.2, AGC ON), 0 lux with IR
- Shutter Speed1/1 s to 1/30000 s
- Slow ShutterYes
- Day & Night[Panoramic channel] Color, [PTZ channel] IR cut filter
- Zoom[PTZ channel] 42 × optical, 16 × digital
- Max. Resolution[Panoramic channel] 3840 × 1080, [PTZ channel] 2560 × 1440
- Lens
- FocusAuto,semi-auto,manual
- Focal Length[Panoramic channel] 2.8 mm, [PTZ channel] 5.9 to 247.8 mm
- Zoom Speed[Panoramic channel] approx. 0 s, [PTZ channel] approx. 5.5 s
- FOV[Panoramic channel] horizontal field of view: 190° ± 5°, vertical field of view: 50±5°, diagonal field of view: 198±5°, [PTZ channel] horizontal field of view: 56.6° to 3.1°, vertical field of view: 34.2 ° to 1.1°, diagonal field of view: 67.1° to 2.3°
- Aperture[Panoramic channel] F1.0, [PTZ channel] F1.2
- Illuminator
- Supplement Light Range[Panoramic channel] white light: up to 30 m, [PTZ channel] IR: up to 300 m
- Smart Supplement LightYes
- PTZ
- Movement Range (Pan) [PTZ channel] 0° to 360°
- Movement Range (Tilt)[Panoramic channel] 7° to 17°, [PTZ channel] -20° to 90°
- Pan Speed[PTZ channel] pan speed: configurable from 0.1° to 160°/s, preset speed: 240°/s
- Tilt Speed[Panoramic channel] tilt speed configurable,[PTZ channel] tilt speed: configurable from 0.1° to 120°/s, preset speed 200°/s
- Proportional Pan[Panoramic channel] No, [PTZ channel] Yes
- Presets300
- Patrol Scan8 patrols, up to 32 presets for each patrol
- Pattern Scan4 pattern scans, record time over 10 minutes for each scan
- Power-off MemoryYes
- Park ActionPreset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama scan
- 3D PositioningYes
- PTZ Status DisplayYes
- Preset FreezingYes
- Scheduled TaskPreset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama scan,dome reboot,dome adjust,aux output
- Video
- Main Stream[Panoramic channel] 50 Hz: 25 fps (3840 × 1080), 60 Hz: 24 fps (3840 × 1080),[PTZ channel] 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720), 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
- Sub-Stream[Panoramic channel] 50 Hz: 25 fps (1920 × 536), 60 Hz: 24 fps (1920 × 536),[PTZ channel] 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288), 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
- Third Stream[Panoramic channel] No,[PTZ channel] 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288), 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
- Video CompressionMain stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264/MJPEG
- Video Bit Rate32 Kbps to 16 Mbps
- H.264 TypeBaseline profile,Main profile,High profile
- H.265 TypeMain profile
- Scalable Video Coding (SVC)H.264 and H.265 encoding
- Region of Interest (ROI)8 fixed regions for each stream
- Audio
- Audio CompressionG.711,G.722.1,G.726,MP2L2,PCM,AAC
- Audio Bit Rate32 to 192 Kbps (MP2L2),16 to 64 Kbps (AAC)
- Audio Sampling Rate8 kHz,16 kHz,32 kHz,48 kHz
- Environment Noise FilteringYes
- Network
- APIISUP,ISAPI,SDK,Open Network Video Interface (Profile S, Profile G, Profile T)
- Network StorageNAS (NFS, SMB/CIFS),auto network replenishment (ANR)
- ProtocolsIPv4/IPv6,HTTP,HTTPS,802.1X,QoS,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP/IP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,FTP
- Simultaneous Live ViewUp to 20 channels
- User/HostUp to 32 users. 3 user levels: administrator, operator, and user
- SecurityPassword protection,complicated password,IP address filter,HTTPS encryption,802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5),host authentication (MAC address),watermark
- ClientiVMS-4200,HikCentral Pro,Hik-Connect
- Web BrowserIE 10+, Chrome 57+, Firefox 52+, Safari 12+
- Image
- Day/Night SwitchDay,night,auto,schedule
- Image EnhancementHLC,3D DNR
- Wide Dynamic Range (WDR)[Panoramic channel] No, [PTZ channel] 120 dB
- DefogOptical defog
- Image StabilizationEIS
- Regional ExposureYes
- Regional Focus[Panoramic channel] No, [PTZ channel] Yes
- Image SettingsSaturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
- Image Parameters SwitchYes
- Privacy Mask[Panoramic channel] No, [PTZ channel] 24 programmable polygon privacy masks; mask color or mosaic configurable
- SNR≥ 52 dB
- Supplement Detection
- Satellite PositioningNo
- GyroscopeYes
- CompassNo
- Interface
- Ethernet Interface1 RJ45 100M self-adaptive Ethernet port
- On-board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
- Alarm7 input(s), 2 output(s)
- Audio1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%, 1 output (line out), line level, output impedance: 600 Ω
- RS-4851 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
- ResetYes
- Event
- Basic Eventvideo tampering alarm,exception,alarm input and output
- Smart EventLine crossing detection,intrusion detection,region entrance detection,region exiting detection,audio exception detection
- Smart TrackingManual tracking,auto-tracking,panorama tracking
- Alarm LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,audible warning,white light flashing,and PTZ actions (such as preset, patrol scan, pattern scan)
- Deep Learning Function
- Multi-Target-Type DetectionSupports simultaneous detection and capture of human body, face and vehicle
- General
- General Functionmirror,password protection
- Power36 VDC ± 25%, max. 70 W,including max. 6 W for heater and max. 6 W for supplement light of panoramic channel, and max. 6 W for heater and max. 15 W for supplement light of PTZ channel
- Operating Condition-40 °C to 70 °C (-40 °F to 158 °F). Humidity 95% or less (non-condensing),For speaker: -30 °C to 55°C (-22°F to 131°F)
- WiperYes
- DemistYes
- MaterialADC12
- DimensionØ290 mm × 453.2 mm (Ø11.42" × 17.84")
- Approx. 11.5 kg (25.35 lb.)
- Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- Approval
- EMCFCC (47 CFR Part 15, Subpart B),CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014),RCM (AS/NZS CISPR 32: 2015),IC (ICES-003: Issue 7),KC (KN 32: 2015, KN 35: 2015)
- SafetyUL (UL 62368-1),CB (IEC 62368-1: 2014 + A11),CE-LVD (EN 62368-1: 2014/A11: 2017),BIS (IS 13252 (Part 1): 2010/IEC 60950-1: 2005),LOA (IEC/EN 60950-1)
- EnvironmentCE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No 1907/2006)
- ProtectionIP67 (IEC 60529-2013),TVS 6000 V lightning protection, surge protection and voltage transient protection
SADP
Hik-ConnectDer er endnu ikke nogen anmeldelser her. Vi vil være glade for hvis du vil anmelde som den første.
Den professionelle måde at levere strøm, til et PoE-kamera, er gennem netværkskablet.
På den måde behøver man kun at trække et enkelt kabel til hvert kamera - og skal ikke døje med 230V og små strømforsyninger.
Strømmen til kameraet leveres gennem netværkskablet fra enten...
- en optager med indbygget PoE, også kaldet NVR. Et typisk valg for installationer op til og med 8 kameraer.
- en PoE-switch. Populært fortalt en fordelerdåse til netværkskabler. Det typiske valg på store installationer eller hvis man ønsker fleksibel kabelføring.
- en PoE-injector. Kan kun levere strøm til et kamera.
Af samme grund følger der ikke strømforsyning med PoE-kameraer. Du kan bestille en klassisk strømforsyning her, hvis du ikke ønsker at benytte PoE.
