BlackVue DR970X-2CH Plus 8MP 64GB Bilkamera

2CH

4K UHD (Front) + Full HD (Rear), 2.4-5GHz Wi-Fi, Cloud, External LTE Module (Optional)

Front: Black / 118.6mm(L) x 47.4mm(W) x 36mm(H) / 108g
Rear: Black / 67.3mm(L) x 28mm(W) x 25mm(H) / 25g

Coaxial cable

microSD card up to 512GB

Normal recording, Event recording (when impact is detected in normal and parking mode), Manual recording and Parking recording (when motion is detected).
* When using Hardwiring Power Cable, ACC+ will trigger parking mode. When using other methods, G-sensor will trigger parking mode.

YES (hardwiring cable included)

YES

Front: STARVIS 2 CMOS Sensor (Approx. 8.4 M Pixel)
Rear: STARVISTM CMOS Sensor (Approx. 2.1 M Pixel)

Front: Diagonal 146°, Horizonal 125°, Vertical 68°
Rear: Diagonal 131°, Horizonal 107°, Vertical 55°

Front: 4K (3840 x 2160) @ 30 fps
Rear: Full HD (1920 x 1080) @ 30 fps
* Frame rate may vary during Wi-Fi streaming.

H.265 (HEVC) / H.264 (AVC)

Highest (Extreme): 60+10 Mbps
Highest: 25+10 Mbps
High: 12+8 Mbps
Normal: 8+6 Mbps

*60Mbps bitrates only support in H.265(HEVC).

YES (Adaptive)

YES (up to 50)

YES

YES

MP4

Built-in (802.11 a.b.g.n.ac)

YES

Built-in (Dual Band : GPS, GLONASS)

Built-in

Built-in

3-Axis Acceleration Sensor

Front: Recording LED, GPS LED, B/W/L (Bluetooth/Wi-Fi/LTE) LED, Front Security LED
Rear: Rear Security LED

Format Button: Press and hold format button for 5 seconds, and after a beep, release the button. Then, press again and hold for 5 seconds and release the button after a beep to format the microSD card.
Touch Sensor: Pressing the touch sensor triggers manual recording depending on the firmware settings.

-20 °C − 70 °C (-4 °F − 158 °F)

-20 °C − 80 °C (-4 °F − 176 °F )

Approx. 75 °C (167 °F)

Built-in supercapacitor

DC 12V-24V (DC Plug (Ø3.5 x Ø1.1)) to Wires (Black: GND / Yellow: B+ / Red: ACC)

Normal Mode (GPS On/2CH): Avg. 480mA /12V
Parking Mode (GPS Off/2CH): Avg. 370mA /12V
* Actual power consumption may vary depending on use conditions and environment.

Front : FCC, ISED, CE, UKCA, RCM, RoHS, Telec, WEEE, KC
Rear : FCC, ISED, CE, UKCA, RCM, RoHS, WEEE, KC

BlackVue Viewer
* Windows 7 or higher, Mac Sierra OS X (10.12) or higher
BlackVue Web Viewer
* Chrome 71 or higher, Safari 13.0 or higher

BlackVue Application
* Android 8.0 or higher, iOS 13.0 or higher

Adaptive Format-Free File Management System
