Hikvision DS-2CD2443G2-I 4MP PoE

Model/varenr.: DS-2CD2443G2-I
1.149,00
( 919,20 )
Lager: På lager
2.8mm 4mm

Lille, flyttebart, kun til indendørsbrug, meget brugt i butikker.


Med dens 4 MegaPixel billedsensor leverer kameraet et rigtig godt dags billede & med op til 10m IR fungere det godt om natten på korte afstande.
Den indbygget mikrofon giver mulighed for at optage lyd, og høre lyd på live visning.
Få fjernet de fleste ubetydelige optagelser ved klassificering af mennesker og køretøjer.

Kan tilgås fra både smartphone, PC og tablet gennem appen Hik-Connect.
Understøtter Dansk, Svensk, Norsk, Tysk og Engelsk sprog.

  • Camera
  • Image Sensor1/3" Progressive Scan CMOS
  • Max. Resolution2688 × 1520
  • Min. Illumination2 mm: color: 0.008 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR 2.8 mm and 4 mm: color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
  • Shutter Speed1/3 s to 1/100,000 s
  • Day & NightIR cut filter
  • Angle AdjustmentPan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
  • Lens
  • Focal Length & FOV2 mm, horizontal FOV 128.4°, vertical FOV 75.4°, diagonal FOV 147.1° 2.8 mm, horizontal FOV 104.3°, vertical FOV 55.9°, diagonal FOV 123.8° 4 mm, horizontal FOV 83.7°, vertical FOV 43°, diagonal FOV 100.3°
  • Aperture2 mm: F2.0 2.8 mm: F1.6 4 mm: F1.6
  • Lens MountM12
  • DORI
  • DORI2 mm: D: 45.5 m, O: 18.0 m, R: 9.1 m, I: 4.5 m 2.8 mm: D: 56.0 m, O: 22.2 m, R: 11.2 m, I: 5.6 m 4 mm: D: 79.4 m, O: 31.5 m, R: 15.9 m, I: 7.9 m
  • Illuminator
  • IR RangeUp to 10 m
  • Wavelength850 nm
  • Smart Supplement LightYes
  • Video
  • Main Stream50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
  • Sub Stream50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360)
  • Third Stream50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
  • Video Compression Main stream: H.265/H.264/H.264+/H.265+ Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264
  • Video Bit Rate32 Kbps to 8 Mbps
  • H.264 TypeBaseline Profile/Main Profile/High Profile
  • H.265 TypeMain Profile
  • Bit Rate ControlCBR/VBR
  • Scalable Video Coding (SVC)Yes
  • Region of Interest (ROI)1 fixed region for main stream and sub-stream
  • Audio
  • Environment Noise FilteringYes
  • Audio Sampling Rate8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
  • Audio Compression G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC
  • Audio Bit Rate64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/16 Kbps to 64 Kbps (AAC)/32 Kbps to 192 Kbps (MP2L2)/8 Kbps to 320 Kbps (MP3)
  • Network
  • Simultaneous Live ViewUp to 6 channels
  • APIOpen Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK
  • ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets
  • User/HostUp to 32 users. 3 user levels: administrator, operator and user
  • SecurityPassword protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
  • Network StorageNAS (NFS, SMB/CIFS), auto network replenishment (ANR)
  • ClientiVMS-4200, Hik-Connect, Hik-Central
  • Web BrowserPlug-in required live view: IE 10, IE 11 Plug-in free live view : Chrome 57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+
  • Image
  • Wide Dynamic Range (WDR)120 dB
  • Day/Night SwitchDay, Night, Auto, Schedule
  • Image EnhancementBLC, HLC, 3D DNR
  • Image Parameters SwitchYes
  • Image SettingsRotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
  • PIR
  • PIR AngleHorizontal: 90°, vertical: 80°
  • PIR RangeUp to 8 m
  • Interface
  • Built-in MicrophoneYes
  • Built-in SpeakerPower: 1 W. Max. sound pressure level: 10 cm: 91 dB.
  • On-board StorageBuilt-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB
  • Hardware ResetYes
  • Communication Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
  • Event
  • Basic Event Motion detection, video tampering alarm, exception
  • LinkageUpload to FTP/memory card/NAS, notify surveillance center, trigger recording, trigger capture, send email, audible warning
  • Face DetectionYes
  • Deep Learning Function
  • Perimeter ProtectionLine crossing, intrusion Support alarm triggering by specified target types (human and vehicle)
  • General
  • Power12 VDC ± 25%, 0.49 A, max. 5.8 W, Ø5.5 mm coaxial power plug PoE: (802.3af, Class 3, 36 V to 57 V), 0.19 A to 0.12 A, max. 6.8 W
  • Web Client Language33 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
  • General FunctionAnti-flicker, heartbeat, password reset via email, pixelounter
  • Storage Conditions-10 °C to 40 °C (14 °F to 104 °F). Humidity 95% or less (non-condensing)
  • Startup and Operating Conditions-10 °C to 40 °C (14 °F to 104 °F). Humidity 95% or less (non-condensing)
  • Camera MaterialPlastic
  • Camera Dimension2 mm: 102.9 mm × 65.2 mm × 28.8 mm (4.1" × 2.6" × 1.1") 2.8 mm and 4 mm: 102.9 mm × 65.2 mm × 32.6 mm (4.1" × 2.6" × 1.3")
  • Package Dimension150 mm × 125 mm × 99 mm (5.9" × 4.9" × 3.9")
  • Camera WeightApprox. 120 g (0.3 lb.)
  • With Package WeightApprox. 430 g (0.9 lb.)
  • Approval
  • EMCFCC SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4: 2011 +A1: 2014); KC (KN 32: 2015, KN 35: 2015)
  • SafetyUL (UL 62368-1); CB (IEC 62368-1:2014+A11); CE-LVD (EN 62368-1:2014/A11:2017)
  • EnvironmentCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)

Super fedt kamera til indendørs overvågning. Overvågningskameraet kan bruges helt alene eller sammen med alle Hikvisions optagere og er kompatibelt med de fleste kendte NAS som synology og QNAP, samt VMS platforme og ONVIF systemer*.

Den bedste egenskab er klart, at kameraet kan fungere som et lille selvstændig alarmsystem, perfekt til at passe på dit hus, sommerhus, campingvogn, hotelværelse mm.

  • PIR giver dig besked (med billede) når der er bevægelse indendørs, da PIR ikke ser gennem vinduer. PIR kan i øvrigt aktivere den indbygget sirene
  • Mikrofonen gør dig i stand til, at høre hvad der sker omkring kameraet direkte fra din mobil/PC
  • Den indbyggede højtaler kan fungere som sirene eller du kan snakke ud af den, direkte fra din mobil/PC
  • Hvis du tilkøber et SD kort kan du afspille optagelserne direkte fra din mobil
  • WDR (Wide dynamic range) giver dig gode billeder selv i stærkt modlys
  • Hik-connect gør, at du kan forbinde direkte til kameraet fra din mobil, du skal hverken åbne port eller skifte offentlige ip adresser.
  • Se en video om kameraet her: https://youtu.be/AqCg2KEBlq0

Skal du bruge en optager til kameraet, kan denne være et godt bud: https://ipcam-shop.dk/4-kanaler-209/hikvision-ds-7604ni-k1b-4-channel-ip-nvr-p1802

HUSK AT DER MEDFØLGER IKKE STRØMFORSYNING!
Hvis du ikke har strømforsyning, kan du evt. bruge enten:


*3. Part kompatibilitet er noget du selv skal tjekke op på, og denne form for opsætningen supportere vi ikke.
