Uniview NVR502-08B-P8-IQ
Bare giv os et kald på 70701009
Optager med kunstig intelligens, effektiv analyse og indbygget PoE
- NDAA - godkendt chipsystem til kritisk infrastruktur - læs mere her
- gør normale kameraer intelligente med optagerens analyse
- virker med alle kameraer der understøtter ONVIF
- tilslut kamera op til 12 megapixel
- indbygget PoE til alle 8 kameraer
- masser tilslutningsmuligheder (APP, computer, TV og lokalskærm)
- gratis computer-software der samler alle dine kameraer fra flere systemer.
- fiskeøje dewarping giver de bedste billeder fra 360° kameraer
En god stabil optager, der er velegnet til småt- og mellemstort erhverv.
Datablad |
Decoding | Description |
Decoding Format | Ultra 265,H.265,H.264 |
Decoding Capability | NVR502‑08B‑P8‑IQ:Smart Off:2 x 16MP@30, 2 x 12MP@30, 4 x 4K@30, 8 x 4MP@30, 8 x 3MP@30, 8 x 1080P@30 Smart On:2 x 12MP@30, 2 x 4K@30, 6 x 4MP@30, 8 x 3MP@30, 8 x 1080P@30 NVR502‑16B‑P16‑IQ:Smart Off:2 x 16MP@30, 2 x 12MP@30, 4 x 4K@30, 8 x 4MP@30, 10 x 3MP@30, 16 x 1080P@30 Smart On:2 x 12MP@30, 2 x 4K@30, 6 x 4MP@30, 8 x 3MP@30, 12 x 1080P@30, 16 x 720P@30 NVR502‑32B‑P16‑IQ:Smart Off:2 x 16MP@30, 2 x 12MP@30, 4 x 4K@30, 8 x 4MP@30, 10 x 3MP@30, 16 x 1080P@30, 32 x 720P@30 Smart On:2 x 12MP@30, 2 x 4K@30, 6 x 4MP@30, 8 x 3MP@30, 12 x 1080P@30, 24 x 720P@30, 32 x D1 |
Audio Compression | G.711A,G.711U |
Network | Description |
Incoming Bandwidth | Smart Off:320Mbps Smart On:160Mbps |
Outgoing Bandwidth | 160Mbps |
Remote Users | 128 |
Protocols | TCP/IP;P2P;NTP;DHCP;PPPoE;HTTP;HTTPS;DNS;DDNS;SNMP;SMTP;NFS;RTSP;IPV6 |
Browser(Plugin) | Windows:IE(IE10/11),Firefox (version 52.0 and above),Chrome(version 45 and above),Edge(version 79 and above) |
Video/Audio Input | Description |
IP Video Input | NVR502‑08B‑P8‑IQ:8‑ch NVR502‑16B‑P16‑IQ:16‑ch NVR502‑32B‑P16‑IQ:32‑ch |
RCA Audio Input | 1‑ch |
Video/Audio Output | Description |
HDMI Output | HDMI:4K(3840x2160)/30Hz, 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
VGA Output | VGA:1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
RCA Audio Output | 1‑ch |
Liveview Display | NVR502‑08B‑P8‑IQ:1/4/6/8/9 NVR502‑16B‑P16‑IQ:1/4/6/8/9/16 NVR502‑32B‑P16‑IQ:1/4/6/8/9/16/25/32 |
Corridor Mode Screen | NVR502‑08B‑P8‑IQ:3/4/5/7/9 NVR502‑16B‑P16‑IQ:3/4/5/7/9/10/12/16 NVR502‑32B‑P16‑IQ:3/4/5/7/9/10/12/16/32 |
Two-way Audio | Description |
Two-way Audio | 1‑ch,RCA(Using the audio input and output) |
Snapshot | Description |
FTP/Schedule/Event Snapshot | 4‑ch snapshot,up to 4K resolution |
Recording | Description |
Recording Resolution | 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P/D1/2CIF/CIF |
Synchronous Playback in Local | 16‑ch |
Smart | Description |
VCA Detection by IPC | Vehicle Detection;SIP(Intrusion Detection,Cross Line Detection,Enter Area,Leave Area);Ultra Motion Detection(UMD);Temperature Detection(Fire Detection,Smoking Detection,Temperature Measurement,Smoke and Fire Detection);People Counting(People Flow Counting,Crowd Density Monitoring);Video Metadata;Traffic Monitoring |
Smart by NVR | Smart Intrusion Prevention (SIP);Ultra Motion Detection(UMD) |
VCA Search | Motor Vehicle Search;Non‑Motor Vehicle Search; General Search;People Counting Report;Heat Map |
Smart by IPC | All channels (up to 8 images/s in total) Vehicle Detection,Temperature Detection,SIP,UMD,Video Metadata,Traffic Monitoring |
Search by Image | Support |
Vehicle Picture Library | Up to 5 vehicle picture libraries,with up to 25,000 vehicle pictures in total |
SIP by NVR | 4‑ch |
UMD by NVR | 8‑ch |
Capacity of Snapshot Records | 2 millions records for vehicle snapshot;3 millions records for SIP;2 millions records for video Metadata |
Alarm | Description |
General Alarm | Defocus Detection;Scene Change Detection;Object Left Behind;Object Removed;Auto Tracking;Motion Detection;Tampering;Human Body Detection;Video Loss;Alarm Input;Audio Detection |
Alert Alarm | IP Conflict;Network Disconnected;Disk Offline;Disk Abnormal;Illegal Access;Hard Disk Space Low;Hard Disk Full;Recording/Snapshot Abnormal;Array Damaged;Array Degraded |
GUI Language | Description |
GUI Language | 38 languages: Simplified Chinese, Traditional Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian, Estonian, Bulgarian, Greek, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenia, Serbia, Korean, Japanese, Latvian, Lithuanian, Persian |
Hard Disk | Description |
SATA | 2 SATA Interfaces |
Capacity | Up to 16TB for each HDD(The maximum HDD capacity varies with environment temperature) |
Disk Group | Support |
Redundant Storage | Support |
Disk Array Type | RAID 1 |
External Interface | Description |
Network Interface | 1 RJ45 10M/100M/1000M self‑adaptive Ethernet Interface |
USB | Front panel: 1 x USB2.0;Rear panel: 1 x USB2.0, 1 x USB3.0 |
RS485 | 1 |
RS232 | N/A |
Alarm In | 8‑ch |
Alarm Out | 2‑ch |
Power Supply | AC 100~240V |
Power Switch | Support |
PoE | Description |
Interface | NVR502‑08B‑P8‑IQ:8 RJ45 10M/100M self‑adaptive Ethernet Interface NVR502‑16B‑P16‑IQ/NVR502‑32B‑P16‑IQ:16 RJ45 10M/100M self‑adaptive Ethernet Interface |
Max Power | NVR502‑08B‑P8‑IQ:Max 30W for single port,Max 130W in total NVR502‑16B‑P16‑IQ/NVR502‑32B‑P16‑IQ:Max 30W for single port,Max 240W in total |
Supported Standard | IEEE 802.3at,IEEE 802.3af |
Working Environment | Description |
Working Temperature | ‑10°C ~ + 50°C (+14°F ~ +122°F) |
Working Humidity | ≤ 90% RH (non‑condensing) |
Power Consumption (without HDD) | ≤ 12W |
Dimensions | Description |
Weight (without HDD) | ≤ 2.7Kg (6.0lb) |
Height | 1U |
Dimensions | 380mm × 322mm × 53mm (15.0"×12.7"×2.1") |
Certification | Description |
Certification | CE, FCC, UL, RoHS, WEEE |
CE | EN 55032, EN 61000‑3‑3, EN IEC 61000‑3‑2, EN 55035 |
FCC | Part15 Subpart B |
Der er endnu ikke nogen anmeldelser her. Vi vil være glade for hvis du vil anmelde som den første.
NDAA Compliant
Det betyder, at udstyret endda må indgå i installationer i kritisk infrastruktur i USA.
Power over Ethernet
ONVIF full member
Alarm in/out
Alarm ind og ud gør det muligt at forbinde kameraer og optagere til andet udstyr.
Hvor stor en harddisk skal jeg vælge?
Optagere leveres som udgangspunkt uden harddisk, for behovet er ikke det samme for alle.
Når du optager din videoovervågning, så er der flere ting der påvirker, hvor meget optagelserne fylder.
Helt oplagt så betyder antallet af kameraer, og deres opløsning meget - men din konfiguration, og hvor meget der sker foran kameraet, har også en betydning.
Udgangspunktet er, at man hellere skal optage en time for meget end et minut for lidt. Omvendt gider normalt kun nordmænd lave videoer, der viser at græsset gror.
Brug beregneren til at få en fornemmelse af dit pladsbehov. Synes du det er spændende, så læs lidt mere om pladsoptimering nederst på siden. Og har du vigtigere ting for - så bare ring til os...
1) Vælg kameraets opløsning...
2) Vælg antal kameraer...
3) Vælg størrelsen på harddisken...
4) Vælg antal timer med optagelse per dag... 6
1 time
24 timer
Resultat:
Lagringspladsen svarer til cirka timers videooptagelse.
Med 6 timers optagelse pr dag, kan du typisk gå dage tilbage i tid.1)
1) Værdierne er tilnærmede, og baseret på typiske indstillinger med 25 billeder i sekundet og h265 komprimering.
