Uniview Gigabit-switch PoE 8+2 ext 30/120W
Model:
NSW2010-10GT-POE-IN
NDAA
999,00
Incl. VAT
(
799,20
Excl. VAT
)
| Datablad |
| Model | NSW2010-5GT-POE-IN | NSW2010-10GT-POE-IN | NSW2010-18GT2GP-POE-IN | NSW2010-26GT2GC-POE-IN |
| Ports | 4×1000Mbps PoE ports (RJ45)+1×1000Mbps ports(RJ45) | 8×1000Mbps PoE ports (RJ45)+2×1000Mbps ports(RJ45) | 16×1000Mbps PoE ports (RJ45)+2×1000Mbps ports(RJ45)+2×1000Mbps ports（SFP） | 24×1000Mbps PoE ports (RJ45)+2×1000Mbps ports(RJ45)+2×1000Mbps ports（Combo） |
| Standards | IEEE802.3, IEEE802.3u, IEEE802.3az, IEEE802.3x, IEEE802.3af, IEEE802.3at | IEEE802.3, IEEE802.3u, IEEE802.3z, IEEE802.3ab, IEEE802.3x, IEEE802.3af, IEEE802.3at, IEEE802.3az | ||
| Switching capacity | 10Gbps | 20Gbps | 40Gbps | 56Gbps |
| Forwarding performance | 7.44Mpps | 14.88Mpps | 29.76Mpps | 41.7Mpps |
| Packet Buffer | 1M bit | 2Mbit | 4M bit | 4Mbit |
| MAC | 2K | 2K | 8K | 8K |
| Dimensions (W×D×H) | 140mm x 76.7mm x 27.7mm (5.5"×3"×1.1") |
220mm x 150mm x 44mm (8.7"×5.9"×1.7") |
280mm x 180mm x 44mm (11"×7.1"×1.7") |
440mm x 207mm x 44mm (17.3"×8.1"×1.7") |
| Weight | <1kg | <1.24kg | <4.2kg | <5kg |
| Input Voltage | AC: 100-240V, 50/60Hz | |||
| MAX. Power | 65W | 130W | 200W | 400W |
| PoE | 802.3at/af | |||
| Max. PoE Power | Max capacity: 60W Max capacity for single port: 30W |
Max capacity: 120W Max capacity for single port: 30W |
Max capacity: 185W Max capacity for single port: 30W |
Max capacity: 370W Max capacity for single port: 30W |
| Cooling Fans | 0 | 1 | 1 | 2 |
| Operating Temperature | 0°C ~ 40 °C | |||
| Storage Temperature | -40 °C ~ 70 °C | |||
| Operating Humidity | 10% ~ 90% non-condensing | |||
| Storage Humidity | 5% ~ 90% non-condensing | |||
| Indicator | PWR(Green), LNK/ACT(Green), PoE(Orange) | |||
| Working Mode | No | Default(Normal mode) : All ports can communicate with each other. VLAN(Secure mode): Downlink ports can communicate only with uplink ports. EXTEND(Surveillance mode): Transmission distance up to 250 meters. Downlink ports can communicate only with uplink ports. |
||
There is no reviews yet. Be the first to write us your opinion
NDAA Compliant
Our models from Uniview, Bosch and Axis are NDAA compliant (National Defense Authorization Act).
This means that the equipment are trusted to be used in critical infrastructure in the US.
This means that the equipment are trusted to be used in critical infrastructure in the US.
Power over Ethernet
Do like the professionals. POE means that only one cable is needed for the camera. The camera gets power through the network cable, typically from a recorder with built-in PoE, or from a POE switch.
