Jablotron JA-112M BUS module for wireless magnetic contacts - 2 indg
JA-112M BUS is a module made for connecting wired magnets. The device both communicates and is supplied through the BUS cable. It is possible to set the unit for reverse input response and in addition, the time for activation at input can be adjusted (from 0.15 to 300 sec). The unit has two programmable and independent inputs NC, NO or balanced with resistors.
Note that the unit occupies two seats in the control panel.
|Voltage from the central bus||12 V (9 ... 15 V)|
|Power consumption in standby mode||5 mA|
|Power consumption with cable||10 mA|
|Max. length of cable||100 m|
|Dimensions||110 x 44 x 26 mm|
|Operating temperature||-10 ° C to + 40 ° C|
