Jablotron JA-180W Wireless combined PIR / microwave detector

Model: JA-180W
Availability: In stock
Log in here to buy
Do you have questions about the product? +45 70701009

JA-180W is a wireless combined PIR and microwave detector, which is intended for places that may be problematic for a normal PIR detector. It can, for example, be a place with frequent temperature changes, air heating or the like. When the PIR detector is activated, MW is also activated, which scans the area to confirm movement in the area. If it turns out that there are people in the area, the alarm is confirmed and a signal goes on to the JA-100 control panel. If you want, you can easily optimize the detector with alternative lenses, as it is compatible with Jablotron's JS-7904 corridor lens, JS-7906 pet lens and JS-7901 curtain lens.

The detector is addressable and takes up a space in the control panel.

Technical specifications

Supply voltage Lithium type LST14500 (3.6V AA)
Rated power 21 μA
Maximum current 38 μA
Battery low voltage ≤ 2.6 V
Typical battery life ca. 2 years (DIP no. 3 to NORM)
Communication tape 868.1 MHz, Jablotron protocol
Communication area ca. 300 m (open area)
Recommended installation height 2.0 to 2.5 m above floor level
PIR detection angle / detection range 110 ° / 12 m (with base lens)
Coverage MW 0.5 to 15 m / 9.35 GHz
Dimensions 110 x 60 x 51 mm
Weight 114 g
Temperature range -10 ° C to + 40 ° C
Working environment indoor use according to EN 50131-1, II
