Hikvision DS-2CD2387G2-LU 8MP ColorVu PoE
DS-2CD2387G2-L has been discontinued - and replaced by DS-2CD2387G2H-LISU/SL
DS-2CD2387G2H-LISU/SL is an improved version of DS-2CD2387G2-L with various improvements, including Human & Vehicle detection, which is an incredibly smart system that automatically detects people and cars in the recordings.
Read a lot more about it - and everything else on the product page for the new version: DS-2CD2387G2H-LISU/SL
We have kept the product page for the DS-2CD2387G2-L so that you always have easy access to the documentation.
ColorVu provides beautiful color images around the clock - even in low light
- 8 MegaPixel image sensor delivers a stunning image.
- suitable outdoors as it requires very little cleaning.
- built-in artificial intelligence (AcuSense) removes most insignificant footage when classifying people and vehicles.
- built-in microphone allows you to record sound and hear sound on live view.
- if the light conditions get too bad, the camera turns on its built-in white LED.
Get push notifications on your mobile - and access to video directly from your smartphone or PC/tablet.
| DS-2CD2387G2-L | |
| Image Sensor | 1/1.2′′ Progressive Scan CMOS |
| Max. Resolution | 3840 × 2160 |
| Min. Illumination | Color:0.0005 Lux @ (F1.0, AGC ON) |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Day & Night | 24/7 Color imaging |
| Angle Adjustment | Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° |
| Lens | |
| Lens Type | Fixed focal lens, 2.8 and 4 mm optional |
| Focal Length & FOV |
2.8 mm, horizontal FOV 102°, vertical FOV 52°, diagonal FOV 124° |
| Lens Mount | M16 |
| Iris Type | Fixed |
| Aperture | F1.0 |
| Depth of Field | 2.8 mm: 3.1 m to ∞ 4 mm: 3.6 m to ∞ |
| DORI | |
| DORI | 2.8 mm: D: 96 m, O: 38 m, R: 19 m, I: 9 m 4 mm: D: 102 m, O: 40 m, R: 20 m, I: 10 m |
| Illuminator | |
| Supplement Light Type | White Light |
| Supplement Light Range | Up to 30 m |
| Smart Supplement Light | Yes |
| Video | |
| Main Stream | 50 Hz: 25 fps (3840 × 2160, 3200 × 1800 , 2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 24 fps (3840 × 2160) 30 fps (3200 × 1800 , 2688 × 1520, 1920 × 1080, 1280 × 720) |
| Sub-Stream | 50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360) |
| Third Stream | 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 x 1080, 1280 × 720, 640 × 480, 640 × 360) |
| Video Compression | Main stream: H.265/H.264/H.264+/H.265+ Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | CBR/VBR |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Region of Interest (ROI) | 1 fixed region for main stream and sub-stream |
| Audio | |
| Environment Noise Filtering | -U: Yes |
| Audio Sampling Rate | -U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Audio Compression | -U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC |
| Audio Bit Rate | -U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC) |
| Network | |
| Simultaneous Live View | Up to 6 channels |
| API | Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK , ISUP |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP |
| User/Host | Up to 32 users. 3 user levels: administrator, operator and user |
| Security | Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface |
| Network Storage | NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
| Client | iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser | Plug-in required live view: IE 10, IE 11 Plug-in free live view : Chrome 57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+ |
| Image | |
| Wide Dynamic Range (WDR) | 130 dB |
| Privacy Mask | 8 programmable polygon privacy masks, mask color or mosaic configurable |
| Day/Night Switch | Day, Night, Auto, Schedule |
| Image Enhancement | BLC, HLC, 3D DNR |
| Image Parameters Switch | Yes |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| Interface | |
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage | Built-in memory card slot, support microSD/SDHC/SDXC/TF card, up to 256 GB |
| Built-in Microphone | -LU: Yes |
| Event | |
| Basic Event | Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
| Smart Event | Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggering by specified target types (human and vehicle)) Scene change detection |
| Linkage | Upload toNAS/memory card/FTP, notify surveillance center, trigger record, trigger capture, send email |
| Deep Learning Function | |
| Face Capture | Yes |
| General | |
| Power | -L: 12 VDC, 0.42 A, max. 5 W PoE: 802.3af, 36 V to 57 V, 0.17 A to 0.11 A, max. 6.0 W -LU: 12 VDC, 0.46 A, max. 5.5 W PoE: 802.3af, 36 V to 57 V, 0.18 A to 0.11 A, max. 6.5 W |
| Material | Cover: metal, main body: metal |
| Dimension | Ø 138.3 mm × 120.1 mm (Ø 5.4" × 4.7") |
| Package Dimension | 170 mm × 170 mm × 150 mm (6.7" × 6.7" × 5.9") |
| Weight | Approx. 870 g (1.9 lb.) |
| With Package Weight | Approx. 1160 g (2.6 lb.) |
| Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Language | 33 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| General Function | Anti-flicker, heartbeat, mirror, password reset via e-mail, pixel counter |
| Software Reset | Yes |
| Approval | |
| EMC | FCC (47 CFR Part 15, Subpart B) CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014) RCM (AS/NZS CISPR 32: 2015) IC (ICES-003: Issue 7) KC (KN32: 2015, KN35: 2015) |
| Safety | UL (UL 62368-1) CB (IEC 62368-1: 2014+A11) CE-LVD (EN 62368-1: 2014/A11: 2017) |
| Environment | CE-RoHS (2011/65/EU) WEEE (2012/19/EU) Reach (Regulation (EC) No 1907/2006) |
| Protection | IP67 (IEC 60529-2013) |
There is no reviews yet. Be the first to write us your opinion
This camera:
This is the ultimate ColorVu camera (read more about the ColorVu concept below). It has a very good light sensitivity, 30 meters of self-illumination. Note that in the ColoVu series the light is visible, white light. The camera is simply connected to a PoE switch, PoE injector, 12v power supply or a recorder with PoE outputs. The camera has a 1/1.2" Progressive Scan CMOS image sensor - that's good ;)
But it doesn't end there, because generation 2, the DS-2CD2387 G2 -L, means that the camera also has some pretty cool analytics that come as standard and are free to use. The analyzes are i.a. classification of people and vehicles, which is also known from AcuSense. (If you want this feature, but without visible light, look at AcuSense cameras ).
|
Lens |
Horizontal angle (Horizontal) |
Vertical angle (Vertical) |
Diagonal angle (corner to corner) |
| 2.8 mm | 102° | 52° | 124° |
| 4 mm | 88° | 47° | 104° |
The advantage of ColorVu
The ColorVu series is one of the best camera series for the price. What makes the surveillance camera different from other cameras is the light sensitivity, which is really impressive. Unlike conventional surveillance cameras, the camera's own lighting is visible, whereas on others it is IR (InfraRed approx. 850nm). The visible light makes the cameras draw attention to themselves, as the light shines into the eyes and therefore has a very preventive effect. Another advantage of the visible white light is that they can also act as additional light on the building.
To be continued after the video...
Note that we enlarge some shots quite wildly so that the differences between the cameras become more apparent.
Pssst... if you want to know much more about the ColorVu series, read here: https://www.hikvision.com/europe/core-technologies/low-light-imaging/colorvu/
Accessories and extras
If you don't have anything for the camera already, consider these things:
- Current:
- Hard disk recorder (budget solution, primarily for use on phone/tablet):
- Hard disk recorder (pro solution, fast powerful and suitable for use and handling on local screen):
- SD card (for stand-alone or backup if the hard disk recorder is interrupted)
Assembly
The camera can be mounted in all directions, both "upside down" where the camera is mounted, e.g. in an overhang or ceiling, facing sideways, where the camera is mounted on a vertical wall and at an angle, on crooked and inclined surfaces.
If the camera is not mounted on a surface where the assembly can lie on the "other side", a bracket should be considered, see the image below:
If the "tail" of the camera can be on the other side of the mounting surface as shown above, then no bracket is needed.
