Hikvision DS-2DE3C210IX-DE(C1)(T5) 2MP 10x Zoom PTZ PoE+
Model:
DS-2DE3C210IX-DE(C1)(T5)
3.695,00
Incl. VAT
(
2.956,00
Excl. VAT
)
DS-2DE3C210IX-DE(C1)(T5) has been discontinued
DS-2DE3C210IX-DE(C1)(T5) has been discontinued. See our other PTZ cameras here or contact customer service on +45 70701009 for a replacement.
We have kept the product page for DS-2DE3C210IX-DE(C1)(T5) so that you always have easy access to the documentation.
For situations where a fixed position is not enough & you want to get really close.
With its 2 MegaPixel image sensor, the camera delivers a good daytime image & & with up to 50m IR you can also see very far at night.
AcuSense allows the camera to classify people & vehicles.
Powered by Darkfighter is more light-sensitive & can therefore display a color image for a longer period of time.
The built-in microphone allows you to record sound and hear sound on live view.
Loudspeaker emit siren sound or voice messages.
Can be accessed from both smartphone, PC and tablet through the Hik-Connect app.
Supports Danish, Swedish, Norwegian, German and English languages.
- Camera
- Image Sensor1/1.8" Progressive Scan CMOS
- Max. Resolution1920 × 1080
- Min. IlluminationColor: 0.005 Lux @ (F1.3, AGC ON), B/W: 0.001 Lux @ (F1.3, AGC ON), 0 Lux with IR
- Shutter Speed1/1 to 1/30,000 s
- Day & NightIR cut filter
- Zoom10x optical, 16x digital
- Slow ShutterYes
- Lens
- Focal Length2.8 to 28 mm
- FOVHorizontal FOV 108° to 19.8°, vertical FOV 56.4° to 11.5°
- FocusAuto, semi-auto, manual
- ApertureMax. F1.3
- Zoom SpeedApprox. 6.0 s
- Illuminator
- Supplement Light TypeIR
- Supplement Light RangeIR Distance: up to 50 m
- Smart Supplement LightYes
- PTZ
- Movement Range (Pan)355°
- Movement Range (Tilt)0° to 90°
- Pan SpeedPan speed: configurable from 0.1° to 60°/s; preset speed: 60°/s
- Tilt SpeedTilt speed: configurable from 0.1° to 50°/s, preset speed 50°/s
- Proportional ZoomYes
- Presets300
- Preset FreezingYes
- Park ActionPreset, patrol scan
- 3D PositioningYes
- PTZ Status DisplayYes
- Scheduled TaskPreset, patrol scan, dome reboot, dome adjust, auxiliary output
- Power-off MemoryYes
- Video
- Main Stream50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720)
- Sub-Stream50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
- Third Stream50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
- Video CompressionMain stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264/MJPEG
- Video Bit Rate32 Kbps to 16 Mbps
- H.264 TypeBaseline Profile/Main Profile/High Profile
- H.265 TypeMain profile
- Scalable Video Coding (SVC)H.264 and H.265 encoding
- Region of Interest (ROI)8 fixed regions for each stream
- Audio
- Audio CompressionG.711/G.722.1/G.726/MP2L2/PCM/AAC
- Audio Bit Rate64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32-192 Kbps (MP2L2)/16-64 Kbps (AAC)
- Audio Sampling Rate8 kHz/16 kHz/32 kHz/48 kHz
- Environment Noise FilteringYes
- Network
- ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
- Simultaneous Live ViewUp to 20 channels
- APIOpen Network Video Interface (Version 19.12, Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
- User/HostUp to 32 users; 3 user levels: administrator, operator, and user
- SecurityPassword protection, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2/1.3, host authentication (MAC address)
- Network StorageNAS (NFS, SMB/CIFS), ANR
- ClientiVMS-4200, HikCentral Pro, Hik-Connect
- Web BrowserChrome 57+, Firefox 52+, Safari 11+, IE11
- Image
- Image Parameters SwitchYes
- Image SettingsSaturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
- Day/Night SwitchDay, Night, Auto, Schedule
- Wide Dynamic Range (WDR)120 dB
- SNR≥ 55 dB
- DefogDigital Defog
- Image StabilizationEIS
- Image EnhancementBLC, HLC, 3D DNR
- Privacy Mask24 programmable polygon privacy masks, mask color or mosaic configurable
- Regional FocusYes
- Regional ExposureYes
- Interface
- Ethernet Interface1 RJ45 10M/100M self-adaptive Ethernet port
- On-board StorageBuilt-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB
- Built-in Microphone1 built-in microphone
- Built-in Speaker1 built-in speaker
- Audio1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω
- Alarm1 input, 1 output
- Power Output12 VDC, max. 0.7 W
- Event
- Basic EventMotion detection, video tampering alarm, exception, alarm input and output
- Smart EventLine crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detection
- Alarm LinkageUpload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture, audible warning, white light flashing, and PTZ actions (such as preset, patrol scan)
- Deep Learning Function
- Face CaptureDetects up to 30 faces simultaneously. Supports detecting, capturing, grading, selecting of face in motion, and outputs the best face picture of the face
- Perimeter ProtectionLine crossing, intrusion, region entrance, region exiting Support alarm triggering by specified target types (human and vehicle)
- General
- Power12 VDC, Max. 24 W; PoE (802.3at)
- DimensionØ 156.4 mm × 142.1 mm (Ø 6.16" × 5.59")
- Approx. 1.90 kg (4.19 lb.)
- MaterialMetal
- Operating Condition-30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing)
- General FunctionMirror, password protection
- Approval
- EMCFCC SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC VoC (ICES-003: Issue 6, 2019); KC (KN 32: 2015, KN 35: 2015)
- SafetyUL (UL 62368-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2017);
- EnvironmentCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
- ProtectionIP66 (IEC 60529-2013)
