Uniview 4MP Smart PTZ dome 16x IR autotrack
Stylish and discreet PTZ camera with the option of being built-in
- High 2K resolution provides sharp images.
- Auto tracking.
- Connect to hard disk recorder or insert SD card.
- 16X optical zoom for great details at long distances.
- Smart IR with a range of up to 100 meters.
- Smart and free app.
- LightHunter technology provides good images in low light.
With the free app, you can configure and control the camera directly from your phone, wherever you are, as long as you have internet access.
Datablad |
Camera | Description |
Resolution | 4MP |
Sensor | 1/2.9''CMOS |
Min. Illumination | Colour: 0.005 Lux (F1.78, AGC ON) 0 Lux with IR |
Day/Night | IR‑cut filter with auto switch (ICR) |
Shutter | Auto/Manual, 1 ~ 1/100000s |
WDR | 120dB |
S/N | >56dB |
Lens | Description |
Lens type | 5.5~88mm |
Optical Zoom | 16X |
Iris | F1.78‑F3.73 |
Field of View (H) | 50.85°~3.47° |
Field of View (V) | 29.94°~1.95° |
Field of View (D) | 62.55°~4.09° |
DORI | Description |
DORI Distance(Detect) | 127.6m~2048.4m(418.6ft~6720.5ft) |
DORI Distance(Observe) | 51.0m~819.4m(167.4ft~2688.2ft) |
DORI Distance(Recognize) | 25.5m~409.7m(83.7ft~1344.1ft) |
DORI Distance(Identify) | 12.8m~204.8m(41.9ft~672.0ft) |
Illuminator | Description |
Illumination Distance(IR) | Up to 100m (328 ft) IR range |
Wavelength | 850nm |
IR On/Off Control | Auto/Manual |
Video | Description |
Video Compression | Ultra 265; H.265; H.264; MJPEG |
Video stream | Dual streams |
Frame Rate | Main Stream: 4MP(2688*1520),Max 30fps Sub Stream: 720P(1280*720), Max 30fps |
Video Bit Rate | 128 Kbps~16 Mbps |
U-code | Support |
ROI | Support |
OSD | Up to 4 OSDs |
Privacy Mask | 24 areas, up to 4 areas per scene |
Image | Description |
White Balance | Auto; Outdoor; Fine Tune; Sodium Lamp; Locked; Auto2 |
Digital noise reduction | 2D/3D DNR |
Smart IR | Support |
Flip | Normal; Flip Vertical; Flip Horizontal; 180° |
HLC | Support |
BLC | Support |
Defog | Digital Defog |
Intelligent | Description |
Smart intrusion prevention | Support false alarm filtering: Cross line detection, Intrusion detection |
Auto-Tracking | Support, target filtering: vehicle, humanbody |
Events | Description |
Basic Detection | Motion detection; Tampering alarm; Audio detection |
General Function | Watermark; IP Address Filtering; Access Policy; ARP Protection; RTSP Authentication; User Authentication; Alarm input |
Audio | Description |
Audio Compression | G.711U; G.711A |
Audio Bitrate | 128 Kbps |
Two-way Audio | Support |
Suppression | Support |
Sampling Rate | 16KHZ |
Storage | Description |
Edge Storage | Micro SD,up to 256 GB |
Network Storage | ANR; NAS(NFS) |
Network | Description |
Protocols | IPv4; IPv6; IGMP; RTP; ICMP; ARP; TCP; UDP; DHCP; PPPoE; RTSP; RTCP; RTMP; DNS; DDNS; NTP; FTP; UPnP; HTTP; HTTPS; 802.1x; SNMP; QoS; SSL/TLS |
Compatible Integration | ONVIF (Profile S, Profile G, Profile T); API; SDK |
User/Host | Up to 32 users. 3 user levels: administrator, common user and operator |
Security | Password protection; Strong password; HTTPS encryption; Export operation logs; Basic and digest authentication for RTSP; Digest authentication for HTTP; TLS 1.2; WSSE and digest authentication for ONVIF |
Client | EZStation; EZLive; EZView |
Web Browser | Plug‑in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above |
Pan/Tilt | Description |
Pan Range | 360°(endless) |
Pan Speed | 0.1°/s~240°/s |
Tilt Range | –5°~90°(auto flip) |
Tilt Speed | 0.1°/s~120°/s |
Number of Presets | 1024 |
Preset Patrol | 16 patrols, up to 64 presets for each patrol |
Route Patrol | 16 patrols, up to 32 actions for each patrol |
Recorded Patrol | 16 patrols, up to 128 actions for each patrol |
Patrol Stay Time | 15s~1800s |
Home Position | Support |
Interface | Description |
Audio I/O | 1/1 |
Alarm I/O | 2/1 |
Serial Port | 1*RS485 |
Network | 1*RJ45 10M/100M Base‑TX Ethernet |
Certification | Description |
EMC | CE‑EMC (EN 55032: 2015+A11:2020+A1:2020,EN IEC 61000‑3‑2: 2019+A1: 2021,EN 61000‑3‑3: 2013+A1: 2019+A2:2021,EN 50130‑4: 2011+A1:2014) FCC (FCC CFR 47 part15 B, ANSI C63.4‑2014) |
Safety | CE LVD (EN 62368‑1:2014+A11:2017) UL (UL 62368‑1, 2nd Ed., Issue Date: 2014‑12‑01) |
Environment | CE‑RoHS (2011/65/EU;(EU)2015/863) |
Protection | IP66 (IEC 60529:1989+AMD1:1999+AMD2:2013) IK10 (IEC 62262:2002) |
General | Description |
Power | DC12V(±10%,3A), PoE+(IEEE 802.3at) |
Power Consumption | Max 23W |
Power Interface | Ø 5.5mm coaxial power plug |
Dimensions | Ø 167 x 181mm(Ø 6.6” x 7.1”) |
Weight | 2.3Kg(5.07lb) |
Working Environment | ‑40℃~65℃ (‑40°F~149°F), Humidity: ≤95% RH (non‑condensing) |
Storage Environment | ‑40℃~70℃ (‑40°F~158°F), Humidity: ≤95% RH (non‑condensing) |
Surge protection | 6KV |
Reset button | Support |
There is no reviews yet. Be the first to write us your opinion
Den professionelle måde at levere strøm, til et PoE-kamera, er gennem netværkskablet.
På den måde behøver man kun at trække et enkelt kabel til hvert kamera - og skal ikke døje med 230V og små strømforsyninger.
Strømmen til kameraet leveres gennem netværkskablet fra enten...
- en optager med indbygget PoE, også kaldet NVR. Et typisk valg for installationer op til og med 8 kameraer.
- en PoE-switch. Populært fortalt en fordelerdåse til netværkskabler. Det typiske valg på store installationer eller hvis man ønsker fleksibel kabelføring.
- en PoE-injector. Kan kun levere strøm til et kamera.
Af samme grund følger der ikke strømforsyning med PoE-kameraer. Du kan bestille en klassisk strømforsyning her, hvis du ikke ønsker at benytte PoE.
PTZ camera for indoor and outdoor use with autotracking
Perfect for monitoring industry, small businesses and livestock.
The camera can solve many tasks and can be used with Uniview's systems or third-party products, as it supports ONVIF.
Speeddome camera for all platforms
This camera can be rotated, controlled and zoomed in on small details at long distances. It can be operated in many ways and from different platforms. It can for example be connected to an alarm, PLC, push button or similar to activate the camera to drive to a specific position (presets). Presets can be activated via schedule, alarm input, other cameras etc. You can also operate it from mobile, computer, local interface and PTZ keyboard.
The camera can pan and zoom incredibly quickly for its size.
Always at home with mobile access
Access the camera from anywhere in the world with the free app. Whether you use a hard disk recorder (NVR) or the camera as a stand-alone, it can be used license-free on your mobile, tablet and computer. It does not require configuring a router or firewall, as a secure VPN is created between the camera and your phone. You just need to remember your username and password - even when you change phones.
From the app, you can also download recordings and share them via email, cloud storage, etc. You can also share and unshare with your contacts directly from the app.
ONVIF
ONVIF is a common protocol that allows equipment to be connected across brands. For example, you can take a camera from manufacturer X and add it to a recorder from manufacturer Y. This makes it easy to choose the best of several worlds. This also applies to third-party software such as Arcules, Eagle Eye, Milestone, etc.
If you use equipment that supports ONVIF, you get great flexibility that makes it easy to adapt future systems.
Alarm in and out
Cameras that support alarm in and alarm out can work with external equipment.
- Alarm in : The camera has a physical terminal where you can connect two wires. When the wires are shorted, the desired functions in the camera are activated, e.g. start recording or send e-mail. Another scenario could be that the camera's alarm in is connected to a relay in a burglar alarm, so that the camera only records when there is movement when the alarm is armed, and does not record at all when the alarm is disarmed.
- Alarm out : The camera has a physical terminal where you can connect two wires to the input of external equipment. The camera can short-circuit the two wires when special requirements are met or "on-demand". This could be when crossing a line, staying in an area, etc. Another scenario could be opening a gate or gate by manual activation from the app.
Customize the information on the image
By default, the time, date and camera name are displayed on the image, but you can delete, move or change the size and location of this information yourself. You can also have other texts presented on the image, for example the department the camera belongs to. The color of the text changes automatically, so if the background is white, the text changes to black and vice versa. You can also choose transparent text.
Lighthunter
Lighthunter is a technology that makes the camera very sensitive to light and creates excellent images in low light. The technology is developed to create the best images day and night by digitally amplifying the light, putting a larger sensor in the camera and a better aperture (F1.2).
Uniview's U-ISP algorithm reduces image noise and blurring, and improves color, lighting conditions and sharpness. Lighthunter provides a clear improvement in image quality compared to cameras without this technology.
Vandal-proof IK10
This camera is IK10 approved, which means it is vandal resistant. It is still a good idea to mount the camera at a height where it cannot be easily reached and to hide or protect the cable so that it cannot be severed or cut. If you cannot hide the assembly in the wall or overhang, we recommend purchasing a bracket for the camera to best protect the assembly.
Can be used both indoors and outdoors in all weather conditions
This outdoor surveillance camera is suitable for the Nordic climate, as it is resistant to water, moisture, heat and cold. The camera can be mounted horizontally, vertically and upside down. There are several different brackets for mounting the camera.
SD card
This surveillance camera can contain a microSD card, which enables it to store recordings without a hard disk recorder. When the recordings are to be played back, this is done directly from a mobile phone, tablet or computer, from where they can be downloaded, shared with others or uploaded to e.g. Google Drive. The recordings are encrypted on the SD card. This is a good solution if you only need to have a single camera, but if you need to have two or more, we recommend a recorder.
Power and PoE
The camera can be powered in two ways, either by PoE or by 12 volts DC. Most people choose PoE as it provides power from the switch or hard disk recorder. You just need to make sure that you are using a switch or hard disk recorder that supports PoE.
If you cannot run a network cable to the surveillance camera or want to use a switch that does not support PoE, the camera can also be connected to a 12 volt power supply.
PoE generally reaches approximately 70 meters (CAT6), but there are ways to extend the distance, for example by placing several switches in series. Some manufacturers also have technologies that can extend the distance significantly. Please contact us if you need to connect to a camera at distances over 70 meters.
Key features
- High image quality : Equipped with a 4MP 1/2.9" CMOS sensor, delivering sharp and clear images with a resolution of 2688×1520 at 30 frames per second.
- Advanced Compression : Supports Ultra 265, H.265, H.264 and MJPEG compression formats, reducing bandwidth and storage requirements without compromising image quality.
- 16X Optical Zoom : With a 5.5–88mm lens and 16X optical zoom, the camera can capture details at long distances, making it ideal for monitoring large areas.
- LightHunter Technology : Ensures excellent image quality in low light by improving light sensitivity and reducing noise, providing clear images even in low light conditions.
- Smart IR : Infrared illumination with a range of up to 100 meters that adjusts intensity automatically to prevent overexposure of objects close to the camera.
- Rugged design : The camera is IP66 rated for water and dust protection and IK10 rated for vandalism resistance, ensuring reliable operation in harsh environmental conditions.
- Power supply : Supports both DC12V±10% and PoE+ (IEEE 802.3at), providing flexibility in installation.
- Alarm and audio inputs/outputs : Equipped with 2 alarm inputs, 1 alarm output, 1 audio input and 1 audio output, enabling integration with external devices and systems.
Conclusion
The Uniview IPC6434LR-X16-VG1 is a versatile and robust PTZ dome camera that combines advanced features such as LightHunter technology, powerful optical zoom and smart IR illumination. It is perfect for monitoring large areas and challenging environments where image quality and functionality are essential.

Power over Ethernet

ONVIF full member

PTZ
You can control it from your mobile, computer or even a joystick. The camera can also be set to constantly patrol between fixed points.

Auto tracking

Push Notification
When you tap on the message, you can immediately see live images - and a recording of what triggered the message.

Power over Ethernet

ONVIF full member

PTZ
You can control it from your mobile, computer or even a joystick. The camera can also be set to constantly patrol between fixed points.

Autotracking

Alarm in/out
Alarm in and out allows you to connect cameras and recorders to other equipment.

ANR
If there are network problems, the camera stores the recordings on an SD- card - and then sends them to the recorder when the connection is stable again.
