Uniview - 128 channel NVR
128 channel enterprise class NVR with large storage capacity
- Connect cameras with up to 32 megapixels.
- Hotswap hard drives - change hard drives while the system is operating.
- Space for 16 disks of 16TB/each (RAID 0, 1, 5, 6, 10, 50 & 60).
- Redundant power supply can be purchased.
- Supports cloud upgrade.
- 2 HDMI and 2 VGA outputs.
- 8K on HDMI1 and 4K on HDMI2.
- Supports ANR - automatic download of backup to SD card in camera.
A powerful quality recorder for large installations.
| Decoding | Description |
| Decoding Format | Ultra 265,H.265,H.264 |
| Decoding Capability | NVR516-64E-R:2 x 32MP@30, 4 x 16MP@30, 5 x 12MP@30, 8 x 4K@30, 12 x 5MP@30, 16 x 4MP@30, 20 x 3MP@30, 32 x 1080P@30, 54 x 960P@30, 64 x 720P@30 NVR516-128E-R:2 x 32MP@30, 4 x 16MP@30, 5 x 12MP@30, 8 x 4K@30, 12 x 5MP@30, 16 x 4MP@30, 20 x 3MP@30, 32 x 1080P@30, 54 x 960P@30, 64 x 720P@30, 128 x D1 |
| Audio Compression | G.711A,G.711U |
| Network | Description |
| Incoming Bandwidth | 640Mbps |
| Outgoing Bandwidth | 640Mbps |
| Remote Users | 128 |
| Protocols | TCP/IP;P2P;UPnP;NTP;DHCP;PPPoE;HTTP;HTTPS;DNS;DDNS;SNMP;SMTP;NFS;RTSP;802.1x;IPV6 |
| Browser(Plugin) | IE(IE10/11)for Windows,Firefox(version 52.0 and above)for Windows,Chrome(version 45 and above)for Windows,Edge(version 79 and above)for Windows |
| Video/Audio Input | Description |
| IP Video Input | NVR516-64E-R:64-ch NVR516-128E-R:128-ch |
| RCA Audio Input | 1-ch |
| Video/Audio Output | Description |
| HDMI Output | HDMI1:8K(7680x4320)/60Hz,4K(3840x2160)/30Hz,1920x1080/60Hz,1920x1080/50Hz,1600x1200/60Hz,1280x1024/60Hz,1280x720/60Hz,1024x768/60Hz HDMI2:4K(3840x2160)/30Hz,1920x1080/60Hz,1920x1080/50Hz,1600x1200/60Hz,1280x1024/60Hz,1280x720/60Hz,1024x768/60Hz |
| VGA Output | VGA1/VGA2:1920x1080/60Hz,1920x1080/50Hz,1600x1200/60Hz,1280x1024/60Hz,1280x720/60Hz,1024x768/60Hz |
| RCA Audio Output | 2-ch |
| Liveview Display | 1/4/6/8/9/16/25/36/64 |
| Corridor Mode Screen | 3/4/5/7/9/10/12/16/32 |
| Two-way Audio | Description |
| Two-way Audio | 1-ch,RCA(Using the audio input and output) |
| Snapshot | Description |
| FTP/Schedule/Event Snapshot | 16-ch snapshot,up to 1080P resolution |
| Recording | Description |
| Recording Resolution | 32MP/16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P/D1/2CIF/CIF |
| Synchronous Playback in Local | 16-ch |
| Smart | Description |
| VCA Detection by IPC | Vehicle Detection;SIP(Intrusion Detection,Cross Line Detection,Enter Area,Leave Area);Ultra Motion Detection(UMD);Temperature Detection(Fire Detection,Smoking Detection,Temperature Measurement,Smoke and Fire Detection);People Counting(People Flow Counting,Crowd Density Monitoring);Video Metadata;Traffic Monitoring |
| VCA Search | Motor Vehicle Search;Non-Motor Vehicle Search; General Search;People Counting Report;Heat Map |
| Smart by IPC | Total 64-ch(Vehicle Detection,Temperature Detection,SIP,UMD,Video Metadata,Traffic Monitoring) |
| Alarm | Description |
| General Alarm | Defocus Detection;Scene Change Detection;Object Left Behind;Object Removed;Auto Tracking;Motion Detection;Tampering; Video Loss;Alarm Input;Audio Detection |
| Alert Alarm | IP Conflict;Network Disconnected;Disk Offline;Disk Abnormal;Illegal Access;Hard Disk Space Low;Hard Disk Full;Recording/Snapshot Abnormal |
| GUI Language | Description |
| GUI Language | 38 languages: Simplified Chinese, Traditional Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian, Estonian, Bulgarian, Greek, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenia, Serbia, Korean, Japanese, Latvian, Lithuanian, Persian |
| Hard Disk | Description |
| SATA | 16 SATA Interfaces |
| Capacity | Up to 16TB for each HDD |
| Disk Group | Support |
| Redundant Storage | Support |
| Disk Array Type | RAID 0,1,5,6,10,50,60 |
| Hot Swap | Support |
| External Interface | Description |
| Network Interface | 2 RJ45 10M/100M/1000M self-adaptive Ethernet Interface |
| USB | Front panel: 2 x USB2.0;Rear panel: 2 x USB3.0 |
| RS485 | 1 |
| RS232 | 1 |
| Alarm In | 16-ch |
| Alarm Out | 10-ch |
| eSATA | 1 |
| Power Output | 12V |
| Power Supply | AC 100～240V |
| Power Switch | Support |
| Redundant Power Supply | Support |
| Working Environment | Description |
| Working Temperature | -10°C ~ + 55°C (+14°F ~ +131°F) |
| Working Humidity | ≤ 90% RH (non-condensing) |
| Power Consumption (without HDD) | ≤ 50W |
| Dimensions | Description |
| Weight (without HDD) | ≤ 6.5Kg (14.3lb) |
| Height | 3U |
| Dimensions | 482mm × 533mm × 131mm (19.0"×21.0"×5.1") |
| Certification | Description |
| Certification | CE,FCC,UL,RoHS,WEEE |
| CE | EN 55032,EN 61000-3-3,EN IEC 61000-3-2,EN 55035 |
| FCC | Part15 Subpart B |
There is no reviews yet. Be the first to write us your opinion
A high-quality recorder for big jobs
Follow along wherever you are
With Uniview's app for phone, tablet and computer you can access the system no matter where you are. Simply connect the recorder to the internet, download the free app, and watch live or view playback. Multiple users can be on at the same time.
Supports many functions for different tasks
The recorder can also be used for process control. Here are some examples from other customers:
- Alarm in : Put a mark in the recordings when a PLC (Programmable Logic Controller) is activated.
- Alarm in : Receive an image from a camera when an emergency button is activated or a fire door is opened.
- Alarm out : Activate a siren or flashing lights if a thermal camera detects abnormal temperature.
- Open gate : Use a license plate camera to pull a relay in the camera or recorder.
- Heatmap : Get a heatmap of your fisheye cameras to see traffic patterns in the store.
- POS (Point of Sale) : Display receipt prints on the camera image and easily search text lines to find relevant footage.
- People Count : Get statistics on the number of guests.
Create your own control room
Connect a monitor or TV directly to the recorder with an HDMI cable and control the system with a mouse, like a computer. Add external equipment such as a PTZ touch keyboard to control the cameras - this is the most commonly used. The recorder has two HDMI outputs and two VGA outputs, which can be run individually. HDMI1/VGA1 can, for example, show an overview, while HDMI2/VGA2 can show selected cameras. You can choose how they should be divided.
Get notified when people and vehicles enter your property
Receive push notifications on your phone or tablet when a person or vehicle enters a selected area. No subscription or additional costs required.
People counting, facial recognition and license plate scanning
With most Uniview cameras, the recorder can create statistics on guests, facial recognition and license plate recognition to open gates or send messages.
Turn the camera functions on and off with your alarm system
With the one-key disarm function, you can link the alarm system to your surveillance system. When the alarm is armed, you will receive notifications upon detection. When the alarm is disarmed, the cameras only record activity without any further action.
Smart search features
The recorder has many smart features that make it easy to find interesting events:
- App:
- 24/7 recordings
- Exercise recordings
- Intelligent recordings (VCA)
- Local interface:
- 24/7 recordings
- Exercise recordings
- Intelligent recordings (VCA)
- License plates
- Faces
- AcuSearch
- Computer:
- 24/7 recordings
- Exercise recordings
- Intelligent recordings (VCA)
- Faces
- AcuSearch
Alarm in/out
Alarm in and out allows you to connect cameras and recorders to other equipment.
ANR
If there are network problems, the camera stores the recordings on an SD- card - and then sends them to the recorder when the connection is stable again.
Push Notification
When you press the message, you can immediately see live video - and a recording of what has triggered the message.
HDMI / VGA
You can then configure cameras, watch live views and search in recordings - directly on your NVR. It even comes with a mouse.
Hvor stor en harddisk skal jeg vælge?
Optagere leveres som udgangspunkt uden harddisk, for behovet er ikke det samme for alle.
Når du optager din videoovervågning, så er der flere ting der påvirker, hvor meget optagelserne fylder.
Helt oplagt så betyder antallet af kameraer, og deres opløsning meget - men din konfiguration, og hvor meget der sker foran kameraet, har også en betydning.
Udgangspunktet er, at man hellere skal optage en time for meget end et minut for lidt. Omvendt gider normalt kun nordmænd lave videoer, der viser at græsset gror.
Brug beregneren til at få en fornemmelse af dit pladsbehov. Synes du det er spændende, så læs lidt mere om pladsoptimering nederst på siden. Og har du vigtigere ting for - så bare ring til os...
1) Vælg kameraets opløsning...
2) Vælg antal kameraer...
3) Vælg størrelsen på harddisken...
4) Vælg antal timer med optagelse per dag... 6
1 time
24 timer
Resultat:
Lagringspladsen svarer til cirka 1095 timers videooptagelse.
Med 6 timers optagelse pr dag, kan du typisk gå 182 dage tilbage i tid.1)
1) Værdierne er tilnærmede, og baseret på typiske indstillinger med 25 billeder i sekundet og h265 komprimering.
