Ajax KeyPad - Control panel
Nice stylish Keypad
- Makes it easy to connect and disconnect
- Beautiful design
- Easy to install
- White
| Download |
| User manual |
| Technical specifications | |
| Color | WHITE |
| Classification | Radio channel touch keypad |
| Type of keypad | Wireless, touch |
| Installation method | Indoors |
| Compatibility | Operates with all ajax hubs and range extenders |
| Number of buttons | 15 |
| Duress code | Yes |
| User Passcode | Yes |
| Protection against passcode guessing | Yes |
| Arming/disarming indication | Yes |
| Power supply | Battery: 4 × ААA batteries, 3 V (batteries are installed in pairs) |
| Battery life | Up to 2 years |
| Jeweller radio technology | Communication range with central unit — up to 1,700 m in an open space Two-way communication between devices Operating frequencies — 868.0 - 868.6 MHz Self-adjusting RF output power — up to 20 mW Block encryption based on AES algorithm Keypad scanning period — 12 - 300 s |
| Temperature sensor | Available |
| Operating temperature range | From -10°С to +40°С |
| Permissible humidity | Up to 75% |
| Anti-sabotage | Protection against fraud Jamming detection Tamper-resistant |
| Remote setting and testing | + |
| Dimensions | 150 × 103 × 14 mm |
| Weight | 197 g |
There is no reviews yet. Be the first to write us your opinion
Here you can see the compatibility between the various units and Hubs from Ajax
https://ajax.systems/tools/devices-compatibility/
Super nice control panel that makes it easy to connect and disconnect
Deisgnet is incredibly delicious and available in both black and white! The panel allows you to create a panic button that can send an alarm directly to the neighbor or a control center.
You also have the option of controlling partial connection via the control panel. It has a built-in jamming alarm, so if anyone is trying to jam the system, the alarm goes off.
The panel uses encrypted connection
Indication of connection status
Jamming detector / with changing frequency
Up to 1,700m. in the free term
Possibility of partial connection
Possibility of panic code
White
