Dahua NVR4104-P-EI 4 Channel WinSense AI NVR recorder with PoE
Dahua WinSense NVR recorder for 4 cameras with AI technology
- Dahua 4 channel recorder for IP cameras (NVR)
- Can be accessed directly from the APP on mobile and tablet
- Connect TV/Monitor with HDMI and VGA
- Has 4 Integrated PoE ports
- Human and vehicle detection
- Human and vehicle recognition
- Dahua is a strong brand and makes quality products
HDMI cable is included in the package.
System |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Main Processor |
Industrial-grade processor |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating System |
Embedded Linux |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Interface |
Web; Local GUI |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AI |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AI by Recorder |
Face detection, face recognition, perimeter protection, and SMD Plus |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AI by Camera |
Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Perimeter Protection |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Perimeter Performance AI by Recorder (Number of Channels) |
2 channels, 10 IVS rules for each channel |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Perimeter Performance of AI by Camera (Number of Channels) |
4 channels |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Detection |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Attributes |
Gender; age group; glasses; expressions; face mask; beard |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Detection Performance of AI by Recorder (Number of Channels) |
1 channel (up to 12 face images/s each channel) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Detection Performance of AI by Camera (Number of Channels) |
4 channels |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Recognition |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Database Capacity |
Up to 10 face databases with 20,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Recognition Performance of AI by Recorder (Number of Channels) |
4-channel FD (by camera) + FR (by recorder),image stream: 12 face images/s |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Recognition Performance of AI by Camera (Number of Channels) |
4 channels |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SMD Plus |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SMD Plus by Recorder |
4 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SMD Plus by Camera |
4 channels |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio and Video |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Access Channel |
4 channels |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Bandwidth |
80 Mbps incoming, 80 Mbps recording and 80 Mbps outgoing |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution |
16 MP; 12 MP; 8 MP; 6 MP; 5 MP; 4 MP; 3 MP; 1080p; 960p; 720p; D1; CIF |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Decoding Capability |
AI disabled: 2-channel 16 MP@30 fps; 2-channel 12 MP@30 fps; 4-channel 8 MP@30 fps |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Output |
1 HDMI, 1 VGA |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Multi-screen Display |
1st Screen: 1/4 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Third-party Camera Access |
Panasonic, Sony, Samsung, Axis, Pelco, Arecont, ONVIF, Canon |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Compression Standard |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Compression |
Smart H.265+; H.265; Smart H.264+; H.264; MJPEG |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Compression |
G.711a; G.711u; PCM; G726 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Protocol |
HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; PPPoE; DDNS; FTP; Alarm Server; IP Search (Support Dahua IP camera; DVR; NVS; etc.); P2P; auto register |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mobile Phone Access |
iOS; Android |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interoperability |
ONVIF 22.06(Profile T; Profile S; Profile G); CGI; SDK |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Browser |
Chrome; IE9 and later; Firefox |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Recording Playback |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Multi-channel Playback |
Up to 4 channels |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Record Mode |
General, motion detection; intelligent; alarm |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Backup Method |
USB device and network |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Playback Mode |
Instant playback, general playback, event playback, tag playback, smart playback |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General Alarm |
Motion detection; privacy masking; video loss; scene changing; PIR alarm; IPC external alarm |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Anomaly Alarm |
Camera disconnection; storage error; disk full; IP conflict; MAC conflict; login locked; and cybersecurity exception |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Intelligent Alarm |
Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Linkage |
Record; snapshot; IPC external alarm output; audio; buzzer; log; preset; email |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Port |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Input |
1-channel RCA |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Output |
1-channel RCA |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
HDD Interface |
1 SATA port, up to 16 TB.The maximum HDD capacity varies with environment temperature. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
USB |
2 (2 rear USB 2.0 ports) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
HDMI |
1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
VGA |
1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Port |
1 (10/100 Mbps Ethernet port, RJ-45) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE Port |
4 ports, 10/100 Mbps, IEEE 802.3 af/at |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply |
53 VDC, 1.226 A |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption |
Total output of NVR is <10 W(without HDD) Total output power of PoE is 36W,the maximum output power of asingle port is 25.5W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight |
0.50 kg (1.10 lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight |
1.38 kg (3.04 lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Product Dimensions |
204.6 mm × 206.4 mm × 45.6 mm (8.06" × 8.12" × 1.80") (W × L × H) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Packaging Dimensions |
364 mm × 96 mm × 261 mm (14.33" × 3.78" × 10.26") (W × L × H) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Temperature |
–10 °C to +55 °C (14 °F to +131 °F) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Temperature |
–20 °C to +60 °C (–4 °F to +140 °F) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Humidity |
10%–93% (RH) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Installation |
Rack or desktop |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certifications |
FCC: 47 CFR FCC Part15, SubpartB, Class A |
There is no reviews yet. Be the first to write us your opinion
NVR recorder with AI that can handle up to 4 IP cameras
A small network recorder that supports up to four IP cameras in up to 8MP(4K). It is very suitable for home use and small businesses
WizSense (AI)
Is an AI technology from Dahua, which provides an incredible number of cool features in the recorder. Human and vehicle detection allows the recorder to detect if a person or a vehicle is approaching and notify you directly on your mobile phone. The technology has become so good that you almost avoid false alarms.
Human and vehicle recognition is an even smarter feature that makes it possible to recognize, for example, a person's face. If there is a person who looks suspicious, you can go back in the recordings and search for when that face was there. Both of these functions are built into the recorder itself.
The recorder also supports Heat-Mapping and people counting, but only if the camera also supports it.
Watch live and rewind easily, directly from your mobile
With Dahua's app, you can easily rewind recorded footage or watch live, directly from your mobile or tablet. The app is very user-friendly and can be set to the language of your choice.
The system has HDMI and VGA outputs, which also make it possible to connect it to a monitor.
Hard drive
The recorder has space for one hard drive of up to 16TB. You can use our hard drive calculator further down the page to see what size suits your needs.
PoE - Should I choose with or without integrated PoE?
Both models have their advantages. It depends on whether you have already run all your cables or whether you are going to do a completely new installation.
With integrated PoE:
Here you have the PoE ports directly on the back of the recorder, which means you have to pull all the cables from the cameras to the recorder. That way you have everything in one place and the programming itself is a little easier because the recorder itself distributes IP addresses to the cameras.
Without integrated PoE:
This usually gives you a little more flexibility in your installation, but it requires a separate PoE switch. The recorder is often the cheaper option, so the price is about the same.
With a PoE switch, you can do less cable routing, as you have the option of placing the switch on the ceiling, for example. That way, you only have to run the cables from the cameras to the switch, and from there only one cable down to your router and recorder.
With a switch, you can basically connect anything on the network as you want, as long as it's connected to each other. It gives you a lot more flexibility, especially on larger installations.
NVR4104-P-EI has 4 integrated PoE ports
- Supports 1 HDD, up to 16TB
- See "live" and "playback" from the APP
- Connect TV and monitor via HDMI
- Can be controlled with a mouse, like a PC
- Can send push notifications to your mobile
- 1 RJ45 port for network cable - for internet / local network
- USB ports for mouse and USB stick
- 4 PoE Ports
- Human and vehicle detection
- Human and vehicle recognition
- Dahua makes quality products

Hvor stor en harddisk skal jeg vælge?
Optagere leveres som udgangspunkt uden harddisk, for behovet er ikke det samme for alle.
Når du optager din videoovervågning, så er der flere ting der påvirker, hvor meget optagelserne fylder.
Helt oplagt så betyder antallet af kameraer, og deres opløsning meget - men din konfiguration, og hvor meget der sker foran kameraet, har også en betydning.
Udgangspunktet er, at man hellere skal optage en time for meget end et minut for lidt. Omvendt gider normalt kun nordmænd lave videoer, der viser at græsset gror.
Brug beregneren til at få en fornemmelse af dit pladsbehov. Synes du det er spændende, så læs lidt mere om pladsoptimering nederst på siden. Og har du vigtigere ting for - så bare ring til os...
1) Vælg kameraets opløsning...
2) Vælg antal kameraer...
3) Vælg størrelsen på harddisken...
4) Vælg antal timer med optagelse per dag... 6
1 time
24 timer
Resultat:
Lagringspladsen svarer til cirka 1095 timers videooptagelse.
Med 6 timers optagelse pr dag, kan du typisk gå 182 dage tilbage i tid.1)
1) Værdierne er tilnærmede, og baseret på typiske indstillinger med 25 billeder i sekundet og h265 komprimering.
