Hikvision DS-2DE7A412MCG-EB ColorVu PTZ camera
4 MP PTZ camera that can see color at night and detect people
- 12x optical and 16x digital zoom
- Can see color all night
- Up to 150m IR and 100m white light for night shots
- Built-in microphone and speaker
- Auto-tracking – the camera automatically follows moving targets
Super cool camera with many options
- Camera
- Image Sensor1/1.8" Progressive Scan CMOS
- Max. Resolution2560 × 1440
- Min. IlluminationColor: 0.0005Lux @ (F1.2, AGC ON), B/W:0.0001Lux @ (F1.2, AGC ON), 0 lux with light
- Shutter Speed1/1 s to 1/30000 s
- Day & NightIR cut filter
- Zoom12 × optical, 16 × digital
- Slow ShutterYes
- Lens
- Focal Length6.7 mm to 80.4 mm
- FOVHorizontal field of view: 51.5° to 7.9° (wide-tele), Vertical field of view: 30.3° to 4.4° (wide-tele), Diagonal field of view: 57.9° to 9.0° (wide-tele)
- FocusAuto, semi-auto, manual
- ApertureMax. F1.2
- Zoom SpeedApprox. 5.8 s
- Illuminator
- Supplement Light TypeHybrid(IR and White Light)
- Supplement Light RangeWhite light: up to 100 m IR: up to 150 m
- PTZ
- Movement Range (Pan)360°
- Movement Range (Tilt)-15° to 90° (auto flip)
- Pan SpeedPan speed: configurable from 0.1° to 160°/s; preset speed: 240°/s
- Tilt SpeedTilt speed: configurable from 0.1° to 120°/s, preset speed 200°/s
- Proportional PanYes
- Presets300
- Preset FreezingYes
- Patrol Scan8 patrols, up to 32 presets for each patrol
- Pattern Scan4 pattern scans
- Park ActionPreset, patrol scan, pattern scan, auto scan, tilt scan, random scan, frame scan, panorama scan
- 3D PositioningYes
- PTZ Status DisplayYes
- Scheduled TaskPreset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output
- Power-off MemoryYes
- Video
- Main Stream50 Hz：25 fps（2560 × 1440，1920 × 1080，1280 × 960，1280 × 720） 60 Hz：30 fps（2560 × 1440，1920 × 1080，1280 × 960，1280 × 720）
- Sub-Stream50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
- Third Stream50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288); 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
- Video CompressionMain stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264/MJPEG
- Video Bit Rate32 kbps to 16384 kbps
- H.264 TypeBaseline Profile/Main Profile/High Profile
- H.265 TypeMain Profile
- Scalable Video Coding (SVC)H.264 and H.265 encoding
- Region of Interest (ROI)8 fixed regions for each stream
- Audio
- Audio CompressionG.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM, AAC-LC
- Audio Bit Rate64 Kbps (G.711),16 Kbps (G.722.1),16 Kbps (G.726),32 to 192 Kbps (MP2L2),16 to 64Kbps (AAC-LC),8 to 320 Kbps (MP3)
- Audio Sampling RateMP2L2: 16kHz, 32kHz, 48kHz,AAC-LC: 16kHz, 32kHz, 48kHz,PCM: 8kHz, 16kHz, 32kHz, 48kHz,MP3: 8kHz, 16kHz, 32kHz, 48kHz
- Environment Noise FilteringYes
- Network
- ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, WebSocket, WebSockets
- Simultaneous Live ViewUp to 20 channels
- API ONVIF (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP
- User/HostUp to 32 users, 3 user levels: administrator, operator, and user
- SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, TLS 1.3, host authentication (MAC address)
- Network StorageNAS (NFS, SMB/CIFS), auto network replenishment (ANR)
- ClientiVMS-4200, HikCentral Pro, Hik-Connect
- Web BrowserIE11, Chrome 80+, Firefox 80+, Safari 13+, Edge 89+
- Image
- Image SettingsSaturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
- Day/Night SwitchDay, Night, Auto, Schedule
- Wide Dynamic Range (WDR)120 dB
- SNR> 52 dB
- DefogDigital defog
- Image StabilizationEIS
- Image EnhancementBLC, HLC, 3D DNR
- Privacy Mask24 programmable polygon privacy masks, mask color or mosaic configurable
- Regional FocusYes
- Regional ExposureYes
- Interface
- Ethernet Interface1 RJ45 10M/100M self-adaptive Ethernet port
- On-board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
- Built-in Speaker1 built-in speaker with effective distance reaching max. 30 meters
- Audio1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 kΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω
- Alarm2 inputs, 1 output
- ResetYes
- Event
- Basic EventMotion detection, video tampering alarm, exception, alarm input and output
- Smart EventLine crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detection
- LinkageUpload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, audible warning, white light flashing, and PTZ actions (such as preset, patrol scan, pattern scan)
- Smart TrackingManual tracking, auto-tracking
- Deep Learning Function
- Face CaptureDetects up to 5 faces simultaneously. Supports detecting, capturing, grading, selecting of face in motion, and output the best face picture of the face
- General
- Power24 VAC, max. 42 W (including max. 12 W for IR and max. 2 W for heater); Hi-PoE
- DimensionØ 220 mm × 357.3 mm (Ø8.66" × 14.07")
- WeightApprox. 5.5 kg (12.13 lb.)
- MaterialADC12
- Operating Condition-30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing)
- DemistYes
- Approval
- EMCCE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014),RCM (AS/NZS CISPR 32: 2015),IC (ICES-003: Issue 7),KC (KN 32: 2015, KN 35: 2015)
- SafetyUL (UL 62368-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2017); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (SANS IEC60950-1)
- EnvironmentCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
- ProtectionIP67 (IEC 60529-2013),IK10 (IEC 62262:2002),TVS 6000 V lightning protection, surge protection and voltage transient protection
SADP
Hik-ConnectThere is no reviews yet. Be the first to write us your opinion
Den professionelle måde at levere strøm, til et PoE-kamera, er gennem netværkskablet.
På den måde behøver man kun at trække et enkelt kabel til hvert kamera - og skal ikke døje med 230V og små strømforsyninger.
Strømmen til kameraet leveres gennem netværkskablet fra enten...
- en optager med indbygget PoE, også kaldet NVR. Et typisk valg for installationer op til og med 8 kameraer.
- en PoE-switch. Populært fortalt en fordelerdåse til netværkskabler. Det typiske valg på store installationer eller hvis man ønsker fleksibel kabelføring.
- en PoE-injector. Kan kun levere strøm til et kamera.
Af samme grund følger der ikke strømforsyning med PoE-kameraer. Du kan bestille en klassisk strømforsyning her, hvis du ikke ønsker at benytte PoE.
Super cool PTZ camera with many cool features
The camera can notify you on your phone if a person or car enters your property. In addition, it also has the ability to see color all night.
ColorVu technology
Provides full color images even in complete darkness, making it ideal for areas with poor lighting.
Night recording with IR and white light
The camera has both IR light (up to 150 meters) and white LED light (up to 100 meters), so you can choose between discreet surveillance or color at night.
AcuSense technology
The camera is equipped with Hikvision's AcuSense technology, which uses advanced algorithms to distinguish between people, vehicles and irrelevant movements such as rain, leaves or animals.
This means that you only get alerts when it's actually necessary – for example, when someone enters an area outside of opening hours or a car enters a restricted zone. The result is significantly fewer false alarms.
Face detection
The camera can detect and track up to 5 faces at once, even if the people are moving. It automatically identifies the most suitable image based on clarity, face angle and lighting conditions. The feature can be used to document who has been in an area and can be integrated with facial databases or access control systems if desired. The technology also works in real time and supports both surveillance and subsequent search.
Built-in microphone and speaker
Supports two-way communication directly via the camera.
Auto tracking
The camera has built-in autotracking, which means it can automatically follow people or vehicles moving in the image.
IP67 Approved
The camera is IP67 rated (dust and waterproof), IK10 protected against vandalism
Technical specifications
- Image sensor: 1/1.8" CMOS
- Minimum light requirements: 0.0005 lux (Color), 0 lux with IR
- Lens: 6.7–80.4mm (12× zoom)
- Pan/tilt: 360° pan, -15° to 90° tilt, fast movement (pan up to 240°/s)
- WDR: 120dB
- Built-in storage: microSD slot up to 512 GB
- Power supply: 24 VAC or Hi-PoE, max 42 W
- Dimensions and weight: Ø220 × 357 mm, approx. 5.5 kg
- Protection: IP67, IK10, TVS 6000V (lightning/surge)
DORI distances
- Detection: up to 745 m
- Observation: up to 296 m
- Recognition: up to 149 m
- Identification: up to 75 m
Accessories and mounting
Included:
- DS-1602ZJ wall mount
Other fittings:
- DS-1661ZJ (pendant bracket)
- DS-1662ZJ (pendant bracket)
- DS-1604ZJ Series (Wall Mount and Pipe/Corner Mount)
- DS-1663ZJ (Ceiling bracket)
