Hikvision DS-7732NXI-I4/S 32 Channel IP AcuSense NVR
Professional Acusense hard disk recorder for business - full of power
- Good hard disk recorder with extra processing power for private and business use
- Can detect people and vehicles
- Face recognition on 1 camera
- Suitable for solutions with 4K/8MP cameras
- Up to 32 IP cameras / 12 MP cameras can be connected
- 1 x 32 MP camera can be connected
- Space for 4 hard drives for higher reliability
- Deep learning
- Lots of smart features
- Intelligent Analytics
- AI by Device
- AI by Camera
- Engine
- Facial Recognition
- Facial Detection and Analytics Face picture comparison, human face capture, face picture search
- Face Attributes
- Face Picture Library Up to 16 face picture libraries, with up to 10,000 face pictures in total (each picture ≤ 512 KB, total capacity ≤ 150 MB)
- Face Picture Comparison (Captured from Camera) 4-ch face picture comparison alarm
- Facial Detection and Analytics Performance 1-ch human face capture (HD network camera, up to 4 MP, H.264/H.265)
- Motion Detection 2.0
- By Device 16-ch
- By Camera
- Perimeter Protection
- By Device Up to 4-ch 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm; Up to 12 rules in total;Up to 4-ch 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm; Up to 12 rules in total;Up to 4-ch 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm; Up to 12 rules in total
- By Camera
- ANPR
- By Camera
- Vehicle Attributes
- Plate Attributes
- Video and Audio
- IP Video Input 16-ch Up to 12 MP resolution *: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled.
- Incoming Bandwidth 160 Mbps
- Outgoing Bandwidth 256 Mbps
- HDMI 1 Output 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, HDMI1/VGA simultaneous output
- HDMI 2 Output 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, HDMI2/VGA independent output
- VGA Output 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, HDMI1/VGA simultaneous output
- Video Output Mode
- CVBS Output 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
- Audio Output 1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio 1-ch, RCA (2.0 Vp-p, 1 KΩ)
- Decoding
- Decoding Format H.265+/H.265/H.264+/H.264/MPEG4
- Recording Resolution 32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/2CIF/CIF/QCIF *: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled.
- Synchronous Playback 16-ch
- Live View Window Division 1/2/4/6/8/9/16
- Aux Port Window Division 1/2/4/6/8/9/16
- Decoding Capability 16-ch @ 1080p (30 fps)
- Dual-Stream Recording Support
- Stream Type Video, Video & Audio
- Audio Compression G.711ulaw/G.711alaw/G.722/G.726/MP2L2
- Network
- Network Interface 2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
- Remote Connection 128
- Network Protocol TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
- API
- Compatible Browser
- Auxiliary Interface
- Serial Interface RS-485 (half-duplex), RS-232, Keyboard
- SATA 4 SATA interfaces supporting hot-plug
- Capacity Up to 10 TB capacity for each disk
- eSATA 1 eSATA interface
- Alarm In/Out 16/4
- USB Interface Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
- Ctrl 12V
- DC 12V
- General
- GUI Language
- Power Supply 100 to 240 VAC, 50 to 60 Hz
- Consumption ≤ 30 W (without HDD)
- Working Temperature -10 °C to 55 °C (14 °F to 131 °F)
- Working Humidity 10% to 90%
- Chassis 19-inch rack-mounted 1.5U chassis
- Dimension (W × D × H) 445 × 400 ×75 mm ( 17.5"× 15.7" × 3.0")
- Weight ≤ 5.6 kg (12.3 lb)
- Certification
- Obtained Certification
- CE EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
SADP
Hik-ConnectThere is no reviews yet. Be the first to write us your opinion
Perfect for the large system at home, the medium-sized shop or the large property
- Can be installed in a rack cabinet, brackets included
- Supports 4 HDD, up to 10 TB per PCS. High reliability
- See "live" and "playback" from the APP (Hik-connect)
- Connect TV and monitor via HDMI
- Can be controlled with a mouse, like a PC
- Can send push messages to your mobile
- 2 pcs. RJ45 ports for network cable - for internet / local network
- Hikvision is a strong brand and makes quality products
Hvor stor en harddisk skal jeg vælge?
Optagere leveres som udgangspunkt uden harddisk, for behovet er ikke det samme for alle.
Når du optager din videoovervågning, så er der flere ting der påvirker, hvor meget optagelserne fylder.
Helt oplagt så betyder antallet af kameraer, og deres opløsning meget - men din konfiguration, og hvor meget der sker foran kameraet, har også en betydning.
Udgangspunktet er, at man hellere skal optage en time for meget end et minut for lidt. Omvendt gider normalt kun nordmænd lave videoer, der viser at græsset gror.
Brug beregneren til at få en fornemmelse af dit pladsbehov. Synes du det er spændende, så læs lidt mere om pladsoptimering nederst på siden. Og har du vigtigere ting for - så bare ring til os...
1) Vælg kameraets opløsning...
2) Vælg antal kameraer...
3) Vælg størrelsen på harddisken...
4) Vælg antal timer med optagelse per dag... 6
1 time
24 timer
Resultat:
Lagringspladsen svarer til cirka timers videooptagelse.
Med 6 timers optagelse pr dag, kan du typisk gå dage tilbage i tid.1)
1) Værdierne er tilnærmede, og baseret på typiske indstillinger med 25 billeder i sekundet og h265 komprimering.
