Uniview 55" 4K UHD surveillance monitor with HDMI
55" 4K monitor for surveillance, control rooms, video walls and professional around-the-clock use
- 55" IPS panel with 4K UHD resolution
- 3840 × 2160 resolution
- Built for 24/7 operation
- 178° viewing angle horizontally and vertically
- 2 HDMI and 2 DisplayPort inputs
- Built-in 2 × 10W speakers
- Very narrow bezel of just 1.4 mm on three sides
- Automatic image optimization for contrast and color
- VESA 200 × 200 mounting
- Suitable for surveillance, video walls and information display
This 55" 4K monitor is developed for professional installations that require continuous operation. The large screen area makes it easy to monitor many cameras simultaneously, while the 4K resolution ensures detailed images.
The monitor is suitable for surveillance centers, receptions, control rooms, stores, warehouses, production facilities and other places where a large, clear image is important.
| Datasheet |
| Technical specifications | |
| Product type | 55" 4K LED monitor |
| Model | MW3255-F-V2 |
| Display size | 55" |
| Panel type | IPS |
| Backlight | LED |
| Resolution | 3840 × 2160 (4K UHD) |
| Refresh rate | 60 Hz |
| Brightness | 300 cd/m² |
| Contrast ratio | 1200:1 |
| Response time | 8 ms |
| Colour support | 1.07 billion colours |
| Colour gamut | 72% NTSC |
| Viewing angle | 178° horizontal, 178° vertical |
| Pixel pitch | 0.315 × 0.315 mm |
| Active display area | 1209.60 × 680.40 mm |
| Surface treatment | Haze 1%, Anti-Glare, 3H |
| Bezel width | 1.4 mm (top/left/right) 17.66 mm (bottom) |
| Video inputs | 2 × HDMI 2 × DisplayPort (DP) |
| Audio output | 3.5 mm headphone jack |
| Speakers | 2 × 10 W |
| VESA mount | 200 × 200 mm |
| Wall mounting thread | M6, 10 mm depth |
| Power supply | 100–240 V AC, 50/60 Hz |
| Typical power consumption | ≤ 120 W |
| Standby power consumption | ≤ 0.5 W |
| Operating time | 24/7 continuous operation |
| Dimensions | 1226.20 × 708.70 × 74.00 mm (without stand) 1226.20 × 770.50 × 242.91 mm (with stand) |
| Package dimensions | 1325 × 820 × 140 mm |
| Weight | Net: 11.4 kg Gross: 15.5 kg |
| Operating temperature | 0 °C to +40 °C |
| Operating humidity | 20% to 85% RH, non-condensing |
| Storage temperature | −20 °C to +60 °C |
| Storage humidity | 10% to 90% RH, non-condensing |
| Housing material | Plastic |
| Panel lifetime | 30,000 hours |
| MTBF | 50,000 hours |
| OSD languages | English, French, Spanish, Portuguese, German, Italian, Dutch, Swedish, Finnish, Polish, Czech, Russian, Korean, Traditional Chinese, Simplified Chinese, Japanese |
| Optional accessory | HB-4032-E LED Monitor Display Wall Mounting Bracket |
| Certifications | CE, FCC |
| Package contents | 1 × HDMI cable 1 × Quick guide 1 × Remote control 1 × Power cable 1 × Pedestal stand |
| Der tages forbehold for eventuelle fejl og ændringer i specifikationerne / Specifications are subject to change without notice. Errors and omissions excepted. | |
There is no reviews yet. Be the first to write us your opinion
55" 4K UHD monitor for surveillance
With a resolution of 3840 × 2160, the monitor displays four times as many pixels as a traditional Full HD screen.
That delivers a sharper image and makes it easier to see details in both live view and recordings.
For surveillance, this means you can show more camera feeds at once without losing overview.
IPS panel with wide viewing angles
The IPS panel ensures consistent colors and high image quality from virtually any angle.
With a 178° viewing angle both horizontally and vertically, several people can view the screen at the same time without significant shifts in color or contrast.
Built for 24/7 operation
The monitor is designed for continuous, round-the-clock operation.
That makes it well suited for surveillance systems, control rooms and other installations where the screen needs to stay on all the time.
Suitable for video walls
The very narrow bezel of just 1.4 mm on the top, left and right sides makes the monitor ideal for multi-screen setups.
The slim transitions between displays create a more unified image on video walls.
Enhanced image processing
The monitor uses automatic image optimization to improve contrast, detail and color reproduction.
This provides a clearer, more natural image for both surveillance and general viewing.
HDMI and DisplayPort
The monitor is equipped with two HDMI inputs and two DisplayPort inputs.
That makes it possible to connect surveillance recorders, computers, video wall systems and other video sources.
Built-in speakers
The built-in 10W speakers allow you to play audio without extra equipment.
This can be useful for surveillance with audio or for presenting video material.
VESA mounting
The monitor supports VESA 200 × 200 mm.
It can therefore be mounted on wall mounts, monitor arms or other professional mounting solutions.
Quiet operation
The monitor runs without intrusive fan noise.
This makes it suitable for offices, meeting rooms and control rooms where low noise levels are important.
Key technical points
- 55" IPS LED monitor
- 3840 × 2160 4K UHD resolution
- 24/7 operation
- 300 cd/m² brightness
- Contrast ratio 1200:1
- 178° viewing angle
- 60 Hz refresh rate
- 2 × HDMI
- 2 × DisplayPort
- 3.5 mm audio output
- 2 × 10W speakers
- VESA 200 × 200 mm
- Max. power consumption 120W
- Lifespan up to 30,000 hours
- MTBF 50,000 hours
