Uniview Gigabit PoE Switch 8+2 ext 30/120W

Model: NSW2010-10GT-POE-IN
Read about the new exciting replacement here ...
999,00  Incl. VAT
( 799,20  Excl. VAT )
Availability: In stock In stock
Do you have questions about the product? +45 70701009

NSW2010-10GT-POE-IN is discontinued - and replaced by NSW2100-9GT1GP-POE-IN

NSW2100-9GT1GP-POE-IN is an improved version of NSW2010-10GT-POE-IN with various enhancements, including People & Vehicle detection — an incredibly smart system that automatically identifies people and cars in the recordings.

Read more about this — and everything else — on the product page for the new version: NSW2100-9GT1GP-POE-IN





We have kept the product page for NSW2010-10GT-POE-IN so you always have easy access to the documentation.



8+2 port PoE switch for surveillance cameras.

  • Only one network cable to the camera — the switch supplies power through the same cable.
  • 8 ports for cameras + 2 uplink ports for network connection.
  • Supports all types of PoE cameras.
  • Up to 30 watts per port and 120 watts total (most cameras use 5–10 watts).
  • Plug 'n play.
  • Active cooling.
  • Rack brackets included

A solid, robust switch that can handle most tasks at home or in a business.

View full description

PDF
Datablad
  NSW2010-10GT-POE-IN
Hardware Specification
Ports Type 8×1000Mbps PoE ports (RJ45)+2×1000Mbps ports(RJ45)
Standards IEEE802.3, IEEE802.3u, IEEE802.3az, IEEE802.3x, IEEE802.3af, IEEE802.3at
Switching capacity 20 Gbps
Packet Buffer 2 M bit
Forwarding performance 14.88Mpps
MAC 2K
Max. PoE Power Max capacity: 120 W, Max capacity for single port: 30 W
Power supply AC: 100-240 V, 50/60 Hz
PoE support POE
Cooling Fans 1
Weight <1.24kg
Indicator PWR (Green), LNK/ACT (Green), PoE (Orange)
Storage humidity 5%～90% (non-condensing)
Operating humidity 10%～90% (non-condensing)
Dimensions (W×D×H) 220mm x 150mm x 44mm
(8.7"×5.9"×1.7")
Storage Temperature -40 ℃ to 70 ℃
Operating temperature 0 ℃ to 40 ℃ (32 ℉ to 104 ℉)
Working Mode Default (Normal mode) : All ports can communicate with each other, VLAN (Secure mode): Downlink ports can communicate only with uplink ports., Extend (Surveillance mode): Transmission distance up to 250 meters. Downlink ports can communicate only with uplink ports

There is no reviews yet. Be the first to write us your opinion

Add review:

Versatile switch for surveillance and networking

This switch is perfect for most networking tasks. It requires no configuration – just connect power and a network cable to the camera, recorder, router, etc.



Plug 'n play - no configuration needed

Connect surveillance cameras, access points and other PoE devices directly to one of the eight PoE ports. After a few seconds it will start supplying power to the device, indicated by a small LED for each port. About 60 seconds after connection the device will be ready and available on the network.



Easy mode switching with a button on the front

  • Default (normal mode): All ports can communicate with each other.
  • VLAN (secure mode): Downlink ports can only communicate with uplink ports.
  • Extend (surveillance mode): Transmission distance up to 250 meters. Downlink ports can only communicate with uplink ports.


Power over Ethernet

Do it like the pros. PoE means only one cable is needed to the camera. The camera gets power through the network cable, typically from a recorder with built-in PoE, or from a PoE switch.
